CNC Chucker Lathe

CINCINNATI 18C CINTURN, Manufacturer: Cincinnati - Milacron, Model Number: 18C Cinturn, Chuck: 18" 3-Jaw Hydraulic, Horsepower: 50 HP AC Variable Speed, Spindle Speed: Max. 1500 RPM, Axis Travel: 40"Z, 18"X, Turrets: (1) 6 Station ID Turret; (1) 6 Station OD Turret, Control: GE Fanuc, Axis Drives: GE Fanuc AC.

Doosan Lynx 220A CNC Chucker Lathe (subject to buyer verification):Swing Over Bed 20.1"Swing Over Saddle 11.4"Max. Turning Diameter 12.6"**Max. Turning Length 12.7" (**Could be less without use of Tailstock)Bar Capacity 1.8"Spindle Bore 2.1"Spindle Speed 60 6000 RPMMotor 20 / 15 HPTravel Distance X-axis 6.9"Travel ...more

Product, Swing Over Cross Slide 11" Swing Over Table 4.95 Max. Cutting Diameter 5" Bar Capacity 1" X-Axis Travel 12" Z-Axis Travel 8" Spindle Speed 6000 RPM Spindle Bore 1.25" Spindle Collet Nose 5C Spindle Nose Thread 2 3/16"-10 Spindle Drive Motor 5 HP Drive System Direct Speed, Belt Drive Maximum Cutting Feed 500 ...more

Manufacturer:HAAS, Model:HL-2BB, Condition:Used - Fair, Year:1997, Stock #:22277, Status:For Sale, Live Tooling No, Sub Spindle No, Swing 24", Machining Length 20", X Travel 8.45", Z Travel 20", Chuck Size 10", Bar Capacity 2.5", Power 30 hp, Max RPM 3,400 RPM, Turning Dia 10", Tailstock No, *NOTE tailstock stock has ...more

HAAS ST25 Chucker Lathe:SWING 20.75″MACHINING LENGTH 21″# AXIS 2CHUCK SIZE 10″BAR CAPACITY 3″POWER 30 hpMAX RPM 3,400 RPMTURNING DIA 15″TAILSTOCK No:10″ 3 Jaw ChuckChip ConveyorRigid Tapping6 Boring bar holders2 Face turning blocksMultiple wedges for OD turningConsumable Tooling NOT ...more

HARDINGE CNC LATHE, PRICE: Loaded on Truck, Our Warehouse, York, PA …… $6,950.00, HMC Stock # 20228, Machine Serial No.: HC-5849-T, Machine Model No.: HC, New Date: Unknown, Retrofit with 2-Axis CNC Tool Slide with Fagor 8025 Control, Gang Type Tooling, Swing Over Ways: 8", Approx. Travel of Cross Slide: ...more

“Normal wear from use, always well maintained, ready to work!”, HARDINGE Model HC CF Precison CHUCKER, LATHE, Between centers: 13″, Chuck 5 in. 3 jaw., Includes collets yes, Only $4,499.00 USD! Sold as is, shipping not included., Loaded free, warehouse, Montreal, Call us today for any questions you ...more

A special purpose large lathe with two sets of headstock and tool post was designed exclusively to turn turbine discs. After finish turning one side of the disc using one headstock, the other headstock approaches, chucks and moves to its home position to turn the other side of the disc, where time consuming rechucking ...more

MAZAK PMC CNC LATHE Oil Country Pipe threader MAZAK PMC CNC LATHE, Model PMC (Power Master Chucker), CNC Control Mazatrol T Plus, Serial number 129138, Serial number 129136, Year of manufacture 2000, Swing over bed 42", Turning diameter 39", Swing over gap 48", Width of gap 20", X-axis travel 25", Z-axis travel 45" ...more

MAZAK POWERMASTER, Manufacturer: Mazak, Model Number: Powermaster 1600 CNC, Year Manufactured: 1981, Chuck: 30" 3-Jaw Hydraulic, Maximum Swing over Bed: 42", Maximum Swing over Carriage: 36", Maximum Turning Diameter: 42", Maximum Turning Length: 40", X-axis Travel: 24.5", Z-axis Travel: 45", Main Motor: 60 HP ...more

Maximum Swing Over Bed Ways: 42” Maximum Turning Diameter: 39.37” Distance, Turret to Spindle Face: 62.99” Turret Positions: 8 X-Axis travel: 22.5” Z-Axis Travel: 44.88” Spindle Hole: 14-1/2” Spindle Speeds: Approx. to 500 RPM Main Motor: 30/45 KVA Under power : Mazak Fusion 640T ...more

MODEL.: PMNX-1600, MAX TURNING DIAMETER.: 39.370", MAX SWING OVER BED.: 42", MAX CUTTING LENGTH.: 62", SPINDLE BORE.: 12.500", SPINDLE MOTOR.: 60 HP, SPINDLE SPEED.: 500, CHUCK SIZE.: 48", X AXIS TRAVEL.: 22.50", Z AXIS TRAVEL.: 44.88", JORGENSEN CHIP CONVEYOR, Machine Type.Lathes, Chucking, Cnc Manufacturer.MAZAK ...more

MORI-SEIKI LL8B, Flat Bed CNC Lathe, 58 In. Swing Over Bed, POWER 39 In. SMW Auto Block 3-Jaw CHuck w/ A20 spindle mount, 98.5 In.=2500 mm Approx. Z Axis Travel, Fanuc 11T CNC Control, 2-Axis, 14 1/2" Square Heavy duty Twin Turret, 14.2 In. Spindle Bore (Not verified but can prior to inspection), Swing over Crosslide ...more

, Chuck Diameter x 2 10”, Max. Work Diameter 14.9”, Max. Turning Diameter 13.78”, Max. Turning Length 5.51”, Spindle RPM Range 24-3500, Spindle Nose A2-6 Spindle, HP Each 30 HP Spindle, Bore 2.48”, Turret Positions x 2 10, Tool Shank Sizes 1.57” rd, 1.00” sq., X1 & X2 ...more

OKUMA CROWN, 762S-SB CNC LATHE, OSP700L CONTROL, 8" HYD. CHUCK, TAILSTOCK, 75-4200 RPM, 20 HP 240V, CHIP CONVEYOR, UNDER POWER, APPX. 10,000 LBS.

REMEDY CNC GANG TOOL LATHE, PRICE: Loaded on Truck, Our Warehouse, York, PA ………… $21,500.00, HMC Stock # 22218-P, Machine Serial No.: 100161, Machine Model No.: S25L, New Date: 2018, Maximum Machining Diameter: 1", Maximum Bar Capacity: 1", Maximum Turning Length: 4.7", Maximum Longitudinal ...more

1-(used) Tsugami Model C300H-XZ CNC High Precision Automatic Lathe, New 2015., Swing over bed. 260mm (10.2"), Tool stage size. 4.5" x 20.5", Spindle center height over X-slide. 50mm (1.97"), Spindle end to X-slide surface (min/max). 123/423mm (4.84"/16.65"), Spindle nose. 140mm flat, Max spindle bar capacity. 38mm ...more
