Angle Bending Rolls

Product Information, Angle Rolls PRODUCT NEW - ON REQUEST: Type:Hydraulic Diameter of rolls:6" ::Type of rolls: Universal Voltage / Phase:220 / 3 ::Digital Controller Beckhoff Weight:1102 lbs Dimensions:34" x 60" x 55" Capacity:2" x 2" x 3/16", Product Code: 03040137082 Make: Bendmak Model: PRO 55 Condition: New.

Approximate Dimensions 25" x 38" x 42" Driving Rolls 3 Leg In Angle Capacity 2" x 2" x 3/16" Leg Out Angle Capacity 2 3/8" x 2 3/8" x 3/16" Square Bar Capacity 1 1/4" x 1 1/4" Round Bar Capacity 1 3/8" Shaft Speed 7.7-15.6, Remote Operators Stand.

2″ x 2″ x 1/4″ New Angle Roll with Digital Readouts, Standard Tools, Horizontal or Vertical., Voltage: 230/3/60 or 480/3/60 VoltsSpeed Rotation: Single Speed RotationDrive: Planetary Gear Reducers and Hydraulic MotorsHardened Rolls: Induction Hardened Tooling, 52 to 55 Rockwell CAngle Leg-In: 2" ...more

PIPE CAPACITY 2 in SCH. 40 ANGLE CAPACITY 2 in X 2 in X 1/4 in TUBE (MAX.) 2 1/2 in -.125 WALL ROLL SHAFT DIAMETER 40 millimeters CENTER ROLL POSITIONING HYDRAULIC, 10 TONS SHAFT SPEED 10 RPM UNIVERSAL TOOLING INCLUDED 6 5/8 in O.D. PROGRAMMING NC- TOUCHPAD NUMBER OF PROGRAMS 8 DISTANCE BETWEEEN SHAFTS 10.625 inches ...more

Make: Imcar, Model: CPHV60, Year: 2004, Machine Location: Illinois, Imcar CPHV60 Angle Roll (2004), MATERIAL CPHV-50 CPHV-60, Flats, Hard 2 x 5/16 16″ 2-3/8 x 3/8 20″, Flats, Easy 2-3/8 x 5/8 18″ 3 x 3/4 20″, Square Bar 1 12″ 1-1/4 18″, Angle, Leg-out 2 x 3/16 24″ 2 x 1/4 ...more

2" x 2" x 1/4" ROUNDO HYDRAULIC HORIZONTAL ANGLE BENDING ROLL, Manufacturer ROUNDO Model SR-2 Condition Used Serial Number 06815 Stock Number 30285.

Reference #43210, Swebend SB3B-65 2" x 2" x 5/16" Hydraulic Angle Bending Roll, S:, Handheld Operator Control, 3-Roll Angle Roll, Hydraulic Drive with Variable Speed, Digital Readouts for Lower Roll Positions, Dual execution (Vertical or Horizontal Rolling), (5) Sets of Roll Dies, CAPACITY:, Shaft Diameter, Top & ...more

Used Tauring ALFA40H1. This pre-owned Bending Roll is in great working condition and can be securely delivered to your facility floor. If you have any technical questions about this Tauring Bending Roll we can review machine. To request a quote, inquire about rigging and trucking or to schedule an inspection, contact ...more

New GMC Angle Roll Bender with Manual Positioning PRB-55, ISO 9001 certified, 2 schedule 40 pipe is the maximum bending capacity, 2.5 round tube 14 Ga. and 2 square tube, Heavy Duty 3HP AC main motor, 1 top forming roll (manually driven), 2 driven bottom rolls, Robust, all steel and welded framework, 1-year parts only ...more

2.36"8.46"1,700 LBS.3/16"1/4"0.78"1.96"2.36" DIA. X.059" WALL3.93" X 0.078" WALL.

Used 2000 Roundo R3 for sale. This pre-owned Roundo Angle Bending Roll is located in the USA. This Angle Bending Roll is available for a limited time, call us today for a quote. If you have any questions about our Roundo R3 listing, contact us and we will be happy to help., Capacity 3" x 3" x 5/16" ...more

, 1 set of standard rolls, All steel construction, All shafts are made of special hardened ground steel, Bottom rolls move hydraulically, DRO for bottom rolls, Hydraulic adjusted guide rolls, Manual lubrication, Horizontal or vertical working position, Rolls are driven hydraulically, Manufacturer Akyapak APK 81 ...more

MANUAL HEIGHT ADJUSTMENT OF UPPER ROLL, MANUAL VERTICAL & LATERAL ADJUSTMENT OF GUIDE ROLLS, FOUR SET OF ANGLE ROLLS, MISCELANEOUS SPACE PLATES, FOUR SET OD RADIOUS ROLLS, 10 HP MOTOR, WIRED 3 PHASE, 60 CYCLE, 220 VOLTS, FORWARD & REVERSING, CARI SPEED CONTROLLED BY DRUM SWITCH, ROLLING CAPACITY:, 3" X 3" X ...more

SERIAL. 61--8534, MODEL. #1, CAPACITY ANGLE LEG OUT. 3" X 3" X 3/8", MINIMUM INSIDE DIAMETER. 24", CAPACITY LEG IN. 2-1/2" X 2-1/2" X 3/8", MINIMUM INSIDE DIAMETER. 30", CAPACITY ROUNDS. 2", CAPACITY FLAT ON FLAT. 6" X 1" TO 24" MIN DIA, CAPACITY FLAT ON EDGE. 3" X 5/8" TO 36" MIN DIA, LEG IN LEG OUT ATTACHMENTS. YES ...more

2014 Carell 305CN3.1V 3-Roll CNC Double Pinch Angle Roll 3" x 3" x 3/8" #7074 #1, Capacities:, Flat bar on edge: 3" x 1/2", Flat bar on flat: 5" X 1", Square bar: 1-3/4", Round bar: 2", Angle leg-out: 3" X 3/8", Anqle leq-in: 2-1 /2" x 9/32", Square tube: 2-1/2" x 10 GA, Round tube: 3-1/2" x 14 GA, Round pipe schedule ...more

3" X 3" X ⅜" Hydraulic Angle Roll with CN3.1V CNC Control, Radis Input and Guide Rolls., Flat Bar On Edge: 3" X ½", Flat Bar on Flat: 5" X 1", Square Bar: 1-¾", Round Bar: 2", Angle Leg Out: 3" X ⅜", Angle Leg In: 2-½" X ...more

3" X 3" X ⅜" Angle Roll with Hydraulic Guide Rolls., External Roll Dia.: 9-27/32", Shafts: 3-11/32" * 3-11/32", Section Modulus: 1.9 - 1.9, Flat on Edge: 3-½" X ¾" X 30", Flat on Flat: 7" X ¾" 20", Square Bar: 2" X 2" 22" ...more

Eagle Bending/Carell Double Pinch Angle Roll Model: CPD80, Rolling Capacity 3" x 3" x 3/8", Roll Diameter 10.23", Shaft Diameter 3.14", Speed 0 – 16 FPM, Angles, leg out 3″ x 3/8″, Angles, leg in 3″ x 5/16", T Section, leg out 3", C Section leg out 5", Flats on edge 3″ x 1-1/2″ ...more

PIPE (MAX) 3" SCH. 40 ANGLE (MAX.) 3" X 3" X 3/8" TUBE (MAX.) 3.5"-.216 WALL ROLL SHAFT DIAMETER 2.75" CENTER ROLL POSITIONING 16 TONS SHAFT SPEED 8 RPM DISTANCE BETWEEN SHAFTS 15" APPROXIMATE DIMENSIONS 54" X 43" X 57" APPROXIMATE WEIGHT 2,860 LBS., TOUCHPAD CONTROLS WITH DIGITAL CENTER ROLL POSITIONING IN-LINE ...more

Make: Imcar, Model: CPHV-80, Year: 2009, Machine Location: South Carolina, Flats, Hard: 3 x 30, Flats, Easy: 5 x 1 26, Square Bar: 1-¾ 22, Angle, Leg-out: 3 x 42, Angle, Leg-in: 2-½ x 5/16 42, Tee, Leg-out: 3 x 34, Tee, Leg-in: 3 x 5/16 36, C, Leg-out: 5 x 2 28, C, Leg-in: 4 x 2 36, Round Bar: 2 22, 1 ...more

MANUFACTURER: BOLDERINI, MODEL #: BSA-16M, TYPE: VERTICAL, 3" x 3" x 30" WITH TOOLING, MOTOR AND CONTROLS, INCLUDES:, SKID OF DIES AND STANDS.

3 X 3 Angle Roll Machine with Machine Body of Steel (ST-52) Construction, Pro 80 Rolls are Driven by a Hydraulic Motor + Planetary Gearbox and Gears, Shafts Made of Special Steel, Hardened and Grounded, Pro 80 Guide Rolls are in Two Directions Hydraulic Adjustable, one set Standard Rolls, Manual Lubrication, Lower ...more

3.15" x 3.15" x.315" TAURING HYDRAULIC CNC ANGLE, Manufacturer TAURING Model DELTA 60 Year 2007 Condition Used Serial Number 06OD-616 Stock Number 29605 Rolling Speed 7.4 RPM Shaft Working Length 6.3" Shaft Diameters 2.36" Weight, Approximately 2500 LBS.

SERIAL. 955921, MODEL. R4, YEAR NEW. 1995, CAPACITY ANGLE LEG OUT. 3-1/2" X 3-1/2" X 3/8", CAPACITY ANGLES LEG IN. 3" X 3" X 3/8", SMALLEST ANGLES ROLLED. 1" X 1" X 1/8", CAPACITY FLAT ON FLAT. 1" X 7", CAPACITY FLAT ON EDGE. 1" X 3-1/2 @ 32 DIA., CAPACITY SQUARE BARS. 1-3/4", CAPACITY ROUND BARS. 2", CAPACITY PIPE. ...more
