For Sale by Smith Machinery Co
Surplus Record Dealer Since 2001
Location: Ames, IA
Contact Jim Smith
Phone Number: 515...> Show Phone Number 515-233-6330
Let the seller know you found their listing on Surplus Record!
Description
Specifications
Equipped With
Equipped With
| Rated prebend capacity | 0.21 mild steel plate to 20 diameter, by 4 wide |
| Top Roll Diameter | 5 inches |
| Weight | 2200 pounds |
Equipped With
Equipped With
EQUIPPED WITH:
• 2 hp TEFC main drive motor
• 1.5 hp TEFC PBA motor
• NEMA 12 electrical enclosures
• Electrics to NFPA 79 Specifications
• 230/460-volt 3 phase 60 hertz electrics
• 1045 steel rolls
• 20 FPM rolling speed
• All gear drive
• Sealed ball & roller bearings on all rolls and idler gears
• Unique all electric drive via gear motors
• Infinitely variable speed via variable frequency drives
• No Hydraulics
• 30% more effective than hydraulic machines
• Independent adjustment of the pinch roll via a handwheel-wedge-screw arrangement
• Steel bearing cases and bronze wedges
• Bending roll adjusted with handwheel via bronze worm gear/alloy steel screw arrangement, tiltable for cone rolling.
• Instant start, stop, and reverse via guarded foot pedal
• Safety cable on three sides of the machine
• Swing out top roll for easy work piece removal with new easy unlock feature
• Starting groove in pinch roll to facilitate rapid work piece pre-bending and rolling.
• Aluminum scale and pointer to show bending roll position
• Haze gray epoxy and safety blue enamel finish
• Cone Attachment
• Hardened and Polished Rolls
• Circular Grooves 3/8, 1/2, 5/8
• Electric Digital Readout Option
• Power Bending Adjustment
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
• Overhead Support 8' Max (manual) - $6,100
DELIVERY:
8-10 Weeks
• 2 hp TEFC main drive motor
• 1.5 hp TEFC PBA motor
• NEMA 12 electrical enclosures
• Electrics to NFPA 79 Specifications
• 230/460-volt 3 phase 60 hertz electrics
• 1045 steel rolls
• 20 FPM rolling speed
• All gear drive
• Sealed ball & roller bearings on all rolls and idler gears
• Unique all electric drive via gear motors
• Infinitely variable speed via variable frequency drives
• No Hydraulics
• 30% more effective than hydraulic machines
• Independent adjustment of the pinch roll via a handwheel-wedge-screw arrangement
• Steel bearing cases and bronze wedges
• Bending roll adjusted with handwheel via bronze worm gear/alloy steel screw arrangement, tiltable for cone rolling.
• Instant start, stop, and reverse via guarded foot pedal
• Safety cable on three sides of the machine
• Swing out top roll for easy work piece removal with new easy unlock feature
• Starting groove in pinch roll to facilitate rapid work piece pre-bending and rolling.
• Aluminum scale and pointer to show bending roll position
• Haze gray epoxy and safety blue enamel finish
• Cone Attachment
• Hardened and Polished Rolls
• Circular Grooves 3/8, 1/2, 5/8
• Electric Digital Readout Option
• Power Bending Adjustment
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
• Additional Starting Groove - $200
• Third Roll Drive - $1,450
• Power Disconnect - $1,025
• Single Axis Side Support (manual) - $3,900• Power Disconnect - $1,025
• Overhead Support 8' Max (manual) - $6,100
DELIVERY:
8-10 Weeks
