For Sale by S & G Press & Machinery Sales
Surplus Record Dealer Since 1996
Location: Shelby Township, MI
Contact Sergio Gasperoni
Phone Number: 586...> Show Phone Number 586-563-5000
Let the seller know you found their listing on Surplus Record!
Description
Specifications | |||
|---|---|---|---|
| Tonnage | No specs attached | ||
| Stroke | No specs attached inches | ||
| Shut Height | No specs attached inches | ||
| Adjustment | No specs attached inches | ||
| Bed Size | No specs attached | ||
| Ram Area | No specs attached | ||
| SPM | No specs attached | ||
Transfer Specifications: Transfer X-Axis Feed Length (pitch) 0 – 36” Transfer Y-Axis Feed Length (clamp) 0 – 36” Transfer Z-Axis Feed Length (lift) 0 – 24” Transfer Speed (strokes per minute) 25 (Based on 25” pitch / 9” clamp / 3” lift) * (based on a 270 degree transfer angle) Start and finish points of transfer motions (All Axis) Fully programmable. Electrical supply 480V-3Ph-60Hz ‘grounded wye’ Air Supply 90 PSI General Application Specifications: Model: Minster E2-600 Station: TBD Bed Size: TBD Feed Manner: TBD Stroke: 12” Plus Maximum Part and Tooling Weight: 200 lbs. Total *GENERAL INFORMATION The transfer speed noted is based solely on the ability of the transfer to move that programmed distance. Die configuration, part configuration, and press motion can affect actual system performance. Higher speeds may be achieved if, lesser move parameters are required or, larger motors and drives are applied. Prices for these components can be provided upon request. The permissible movement of an axis can fall anywhere within the listed ranges and programmed accordingly. This movement can functionally be used for an application, but movements other than the values listed for the performance calculations will affect the actual SPM. Unless otherwise noted, all references to system speed are based on standard slide motion. If a press is provided with link type slide motion, the motion must be reviewed to determine its affect on overall system speed. Maximum Part and Tooling Weight listed is at maximum speed. Higher loads can be transferred with this system at reduced speeds. Consult Wayne Trail for analysis of system speeds when exceeding this rating. | |||
Get Your Price from S & G Press & Machinery Sales!
