Stefani #KD-HP, Edgebander w/Pre-Mill & Corner Rounding, 0.016"-0.472" edge thickness, 2.36" max. panel thickness, 2.52" cutter height, 2022

STEFANI - KD-HP: Edgebander with Premill & Corner Rounding + EVA or PUR Glue System -- Specifications0.4 - 12 mm Edgebanding cap.; panel thickness (min./max.) 10 - 60 mm (0.375" - 2.375"); panel width: Min 51 mm (2"); panel length: Min 140 mm (5-1/2"), variable feed speed: 10 - 20 MPM (33 - 66 FPM); min. distance between panels: 610 mm (24";). -- Front End equipped with: Air Cushion infeed table to facilitate insertion of large dimension workpieces; table dims: 1,600 mm x 600 mm. Infeed fence with: Mechanical digital indicator to position the fence and determine the stock removal. Also equipped with: Pneumatic panel spacing device to prevent Operator from feeding the panels too close to one another. Antiadhesive unit positioned prior to premilling unit prevents buildup of glue. -- Premilling"RT-E" Premilling unit with: (2) 2.2 kW (3.0 HP) - 12,000 RPM motors with jumping action controlled through the PLC. Cutting heads: Adjustable vertically. The unit is equipped with: Copying devices, which guarantee that material removal is consistent on long or slightly out-of-square panels. 64 mm Tall diamond premill cutters with replaceable inserts. -- EVA + PUR Gluing System Quick Melt System with: "SGP-E" Glue Pot for quick heat up time. Double thermoregulation for easy use of both: EVA and PUR glue.Color change & glue pot cleaning are able to be completed in minutes, as opposed to hours. Automatic temperature kickdown feature: Extends glue life & reduces glue scorching; reverse rotation of the glue roller for the application of solid wood. -- Pressure Section(1) Large dia. TEFLON coated clutch-controlled drive roller & (3) pneumatic pressure idle rollers with opposing 1 tilt: Provides extra pressure along the top & bottom edge. Pressure section equipped with: Pneumatic jumping; unit activates exactly on the leading/trailing edges via the edge detecting sensor that will shut down the feed track when there is no material present to be applied. WORKSTATIONS -- End Trimming Unit. (2) 0.38 kW (1/2 HP) - 12,000 RPM motors; "K-SEL 2" End Trim units. -- T & B Trimming UnitTop & Bottom flush trimming; (2) 0.75 kW (1 HP) - 12,000 RPM Motors; Servo controlled with: Large diameter vertical and horizontal copying devices with precise digital indicators. Unit is equipped with: Servo driven motor to go from one material thickness to another from the Controller. -- Fine Trimming & Corner Rounding Unit(2) 0.60 kW (0.80 HP) - 12,000 RPM Motors. "ROUND-K" Unit: Designed to work as an additional set of trimmers for rounding Top/Bottom, as well as the Front/Rear corners of workpiece with 3 mm PVC edges. Unit is equipped with: Front and lateral copying devices; pneumatic blowers to clean the panel. Dust shrouds surround the cutter and travels with the unit as it trims. Unit can go from thin tape to 3 mm PVC through the controller with: No manual adjustments by the Operator. -- Profile Scraping Unit"RAS/1000" Top & Bottom scrappers for thick PVC. Unit equipped with:
