Manufacturer: South Bend
Model: EVS-CHIPMASTER-II
Year: 1995
Table: 10.00 - 50.00
HP: 5.0
Stock # 62333
1 / 6
Click to zoom in
1 / 6
For Sale by Yoder Machinery Sales
Surplus Record Dealer Since 1960
Location: Holland, OH
Contact Sales
Phone Number: 866...> Show Phone Number 866-692-8933
Let the seller know you found their listing on Surplus Record!
Description
SERIAL ............................... SE39873
MODEL ................................ EVS CHIPMASTER II
AREA OF TABLE ........................ 50" X 10"
SPINDLE SPEEDS, INFINTE VARIABLE ..... 0 TO 5000 RPM
SPINDLE FEEDS (ENGLISH) .............. .0015, .003, .006 IPR
SPINDLE FEEDS (METRIC) ............... .0016,.004 & .008 MMPR
LONGITUDINAL TABLE TRAVEL ............ 33"
CROSS TRAVEL ......................... 16"
VERTICAL KNEE TRAVEL ................. 16"
QUILL TRAVEL ......................... 5"
RAM TRAVEL ........................... 22-3/16"
DISTANCE SPINDLE TO COLUMN ........... 5" TO 27"
TAPER IN SPINDLE ..................... R8
HEAD TILTS, FRONT/BACK ............... 45 DEGREE EITHER WAY
HEAD SWIVELS, LEFT/RIGHT ............. 90 DEGREE EITHER WAY
HARDEN & GROUND ...................... WAYS
AUTOMATIC LUBE ....................... YES
MOTOR ................................ 5 HORSEPOWER
MODEL ................................ EVS CHIPMASTER II
AREA OF TABLE ........................ 50" X 10"
SPINDLE SPEEDS, INFINTE VARIABLE ..... 0 TO 5000 RPM
SPINDLE FEEDS (ENGLISH) .............. .0015, .003, .006 IPR
SPINDLE FEEDS (METRIC) ............... .0016,.004 & .008 MMPR
LONGITUDINAL TABLE TRAVEL ............ 33"
CROSS TRAVEL ......................... 16"
VERTICAL KNEE TRAVEL ................. 16"
QUILL TRAVEL ......................... 5"
RAM TRAVEL ........................... 22-3/16"
DISTANCE SPINDLE TO COLUMN ........... 5" TO 27"
TAPER IN SPINDLE ..................... R8
HEAD TILTS, FRONT/BACK ............... 45 DEGREE EITHER WAY
HEAD SWIVELS, LEFT/RIGHT ............. 90 DEGREE EITHER WAY
HARDEN & GROUND ...................... WAYS
AUTOMATIC LUBE ....................... YES
MOTOR ................................ 5 HORSEPOWER
Get Your Price from Yoder Machinery Sales!
