For Sale by Gibbs Machinery Co
Surplus Record Dealer Since 1956
Location: Warren, MI
Contact Sales Dept.
Phone Number: 586...> Show Phone Number 586-755-5353
Let the seller know you found their listing on Surplus Record!
Description
Specifications:
Max. Outside Diameter (Spur & Helical gears): 12"
Max. Face Width Spur: 6-3/4"
Max. Face Width Helical:Depends on Pitch & Helix Angle
Pressure Angles: 14-1/2" to 30"
Max. Helix Angle: 45 Degree
Pitch Ranges (Two Lead Screws Available): 6 to 48 D.P.
-or 20 to 120 D.P.
Involute Tolerance: 0.0002" or Better
Tooth-to-Tooth Spacing: 0.00015" or Better
Lead or Parallelism Per Inch of Face Width: 0.0002" or Better
Overall Length Not Including Control Box: 7'12"
-Including Control Box: 11'0"
Overall Width: 8'9"
Overall Height: 7'6"
Weight, Net Approximate: 9,500 lbs
Max. Outside Diameter (Spur & Helical gears): 12"
Max. Face Width Spur: 6-3/4"
Max. Face Width Helical:Depends on Pitch & Helix Angle
Pressure Angles: 14-1/2" to 30"
Max. Helix Angle: 45 Degree
Pitch Ranges (Two Lead Screws Available): 6 to 48 D.P.
-or 20 to 120 D.P.
Involute Tolerance: 0.0002" or Better
Tooth-to-Tooth Spacing: 0.00015" or Better
Lead or Parallelism Per Inch of Face Width: 0.0002" or Better
Overall Length Not Including Control Box: 7'12"
-Including Control Box: 11'0"
Overall Width: 8'9"
Overall Height: 7'6"
Weight, Net Approximate: 9,500 lbs
Get Your Price from Gibbs Machinery Co!
