No. 5 Warner & Swasey, M4670, square head ram type turret lathe, 20" swing, 10-1/4" swing over cross slide

SERIAL ..........#2275479

MODEL ........ #4670

SWING OVER BED ................................... 20"

SWING OVER CROSS SLIDE ........................... 10-1/4"

MAXIMUM DISTANCE SPINDLE NOSE TO TURRET FACE ..... 36"

SPINDLE SPEEDS ................................... (32) 25 TO 1000 RPM

CROSS SLIDE FEEDS ................................ (6) .002 TO .019 IPR

LONGITUDINAL CARRIAGE FEEDS ...................... (6) .005 TO .047 IPR

TURRET FEEDS ..................................... (6) .004 TO .045 IPR

DIAMETER OF SPINDLE HOLE ......................... 5"

LONGITUDINAL CARRIAGE TRAVEL ..................... 23"

CROSS TRAVEL ..................................... 10"

TURRET TRAVEL .................................... 13"

TAPER ON CARRIAGE

COLLET NOSE .... YES

COOLANT WITH CHIP PAN .. YES

HORSEPOWER SPINDLE MOTOR ... 20
