Description
Milltronics TL14/40 CNC Engine Lathe
Swing Over Bed: 14 inches
Swing Over Cross Slide: 7.8 inches
Max Center Distance: 36 inches
Hole Through Spindle (Bore): 1.65 inches
Spindle Nose: D1-5-inch Camlock
Spindle Speeds: 100–3,000 RPM
Spindle Motor: 12 HP / 10 HP [1]
Travels and Rates
X-Axis Travel (Cross Slide): 7 inches
Z-Axis Travel (Long Slide): 30.5 inches
Rapid Traverse Rates (X/Z): 300 IPM
Feedrate Range: 0.1 to 100 IPM [1, 2]
Tailstock and Physical Specs
Tailstock Quill Travel: 5.5 inches
Tailstock Quill Diameter: 1.875 inches
Tailstock Quill Taper: #3 MT
Approximate Weight: 4,000 lbs
Standard CNC Control: Milltronics Centurion
Get Your Price from Premier Equipment Inc!
