MDL #VS150, Void Scanner, 905 nm Wavelength, 0.5-150 m Range, 2.76 x 0.18 mrad Beam Divergence

SKU: 139184
Model: VS150
Year: 2012
Condition: Used - Like New
S/N: 11713010
Made In: GREAT BRITAIN
Dimensions: 22.00 (H) x 14.00 (W) x 34.00 (L) inches
Additional Description:
Overview:
- Laser Type: Infrared InGaAs diode
- Wavelength 905 nm
- Beam Divergence 2.76 x 0.18 mrad
- Range Resolution 1 cm
- Maximum Range (white target) Up to 150 m
- Minimum Range 0.5 m
- Vertical Scan Range +135 to -135
- Horizontal Scan Range 0-360
- Angular Accuracy +/- 0.2
- Angular Resolution 0.1
- Tilt Sensors (Pitch/Roll ) +/- 0.2 accuracy using accelerometers
- Environmental Protection IP65 (dust and water resistant)
- Operating Temperature -10 C to +45 C
- Head Weight 5 kg
- System Weight (with case) 23 kg
- Power Supply 10-15 V DC or 110-240 V AC (via adapter)
- Current Draw During Scan 0.8 A
- Typical Accessories 13.5 m rugged cable (data/power), tripod/boom mounts, interface box, battery, optional Wi-Fi module
- Control Software Cavity Profiler VS - for real-time control, 3D visualization, merging scans, and exporting point clouds
