Mazak #E650HS/2000, CNC multi-tasking center, 36.2" swing, 80" turning length, (2) 24" chucks, 6" bar, 1600 RPM, 60 HP, B-axis, 40 ATC, 2004

2004 MAZAK E650HS 2000
SPECIFICATIONS:
Swing Over Bed................... 36.2"
Turning Diameter................. 36.2"
Turning Length................... 80"
Distance Between Spindles........ 86"
Chuck Size 1..................... 24"
Spindle Nose 1................... A2-11
Spindle Bore Diameter 1.......... 6.69"
Bar Capacity 1................... 6"
Spindle Speeds 1................. 1,600 RPM
Spindle Horsepower 1............. 60 hp
Chuck Size 2..................... 24"
Spindle Nose 2................... A2-11
Spindle Bore Diameter 2.......... 6.69"
Bar Capacity 2................... 6"
Spindle Speeds 2................. 1,600 RPM
Spindle Horsepower 2............. 60 hp
B - Axis Head Indexing........... 0.0001
B - Axis Milling Spindle Taper... #50 CT
B - Axis Milling Spindle Speed... 10,000 RPM
ATC For Milling Spindle.......... 40
Tool Diameter.................... 5.31
Tool Length...................... 19.69"
Tool Weight...................... 66 lb
X1 - Axis Travel................. 40.35"
Z1 - Axis Travel................. 82.91"
Y1 - Axis Travel................. 25.6"
C - Axis Indexing 1.............. 0.0001
C - Axis Indexing 2.............. 0.0001
Rapid Traverse Rate - X1......... 1575 ipm
Rapid Traverse Rate - Z1......... 1575 ipm
Rapid Traverse Rate - Y1......... 1575 ipm
Programmable Tailstock........... 'No'
Machine Weight................... 77,900 lb
Control.......................... CNC
Dimensions....................... 368" x 155" x 155"
Weight........................... 77900
EQUIPPED WITH:
MAZATROL 640M E TOWER CNC CONVERSATIONAL CONTROL
CHIP CONVEYOR
HIGH PRESSURE THRU SPINDLE COOLANT
RENISHAW PROBING
AUTO TOOL MEASUREMENT
SPINDLE CHILLER
Y AXIS CONTROL
.0001 DEGREE B-AXIS INDEXING
