Makino #U86, CNC wire Electrical Discharge Machine, Hyper i Control, 48" x 35.8" table, .20"-.30" wire diameter, low hours, 2014

MAKINO U86 CNC WIRE EDM

SPECIFICATIONS:
CNC Control: yes
Type of CNC Control: Hyper i CNC Control
Table Size: 48″ x 35.8″
Max Workpiece Length: 55.1″
Max Workpiece Width: 38.8″
Max Workpiece Weight: 6,614 LBS
X-Axis (Longitudinal Travel): 31.4″
Y-Axis (Cross Travel): 23.6″
Z-Axis (Vertical Travel): 20.47″
U-Axis Travel: ±3.97″
V-Axis Travel: ±3.97″
Wire Diameter Range: .20″ – .30″
Internal Work Tank Dimensions W x D x H: 55.1″ x 35.8″ x 21.64″
Approximate Machine Dimensions: 144″ x 120″
Approximate Machine Height: 120″
Approximate Machine Weight: 12,000 LBS

EQUIPPED WITH:
Hyper i CNC Control, Extra Spools of Wire, Several Spare Filters.

* Low Hour machine, well-maintained, lots of spare parts, ready for work!

FEATURES:
This machine features the Hyper i CNC Control which offers intuitive, interactive & intelligent functions. High Definition 24″ class touch screen that uses pinch/swipe/drag operations. Uncompromising user-friendliness is hallmark of the U86 with Hyper i Control.
HEAT – High Energy Applied Technology – This provides improved machining speeds in poor or difficult flushing conditions while maintaining part straightness and accuracy. This machine has a Split V Wire Guide that requires less maintenance and lasts 34X longer than round guides.
