Lamina #A10048SH, magnetic drill with portable hydraulic unit, 5-1/4 HP, pendant Control, hand feed, portable on wheels, #1MT taper, 5-1/4 HP, 0-625 RPM, #54248

Manufacturer: Lamina
Model: A10048SH
Stock # 54248

For Sale by Yoder Machinery Sales

Platinum Level Dealer
Surplus Record Dealer Since 1960

Description

SERIAL # HYDRAULIC TANK ............... P511R
DRILLING HEAD SERIAL .................. CH12354
DRILLING HEAD MODEL # ................. A10048SH
DRILLING CAPACITY ..................... 13/16" STEEL
TAPPING CAPACITY ...................... 3/4"- 10
SPINDLE SPEEDS (VARIABLE) ............. 0 TO 625 RPM
STROKE OF HEAD ON COLUMN .............. 3-1/8"
TAPER IN SPINDLE ...................... #1MT
TORQUE ................................ 525 IN.LBS
MAGNETIC BASE ......................... YES
MAGNETIC BASE HAS A BATTERY BACK ...... YES
DRILL HEIGHT .......................... 10-5/8"
HAND FEED ............................. YES
UNIT PORTABLE ON WHEELS ............... YES
PENDANT CONTROL ....................... YES
12 GPM HYDRAULIC UNIT ................. @ 1600 PSI
DRILL HEAD (HYDRAULIC) ................ 5-1/4 HORSEPOWER
