For Sale by Blumberg Machinery Co
Surplus Record Dealer Since 1971
Location: Bannockburn, IL
Contact Jerry/ Ryan
Phone Number: 847...> Show Phone Number 847-580-6800
Let the seller know you found their listing on Surplus Record!
Description
| Table set up area | 54x10 in |
| Table load capacity (max.) | 770 lbs |
| Travel X-axis | 31.5 in |
| Travel Y-axis | 15 in |
| Travel Z-axis | 15 in |
| Speed range | 70 - 3,600 rpm |
| Spindle mount | ISO 40 |
| Quill stroke | 5 in |
| Quill feeds | (3) 0,04; 0,08; 0,15 in/R |
| Motor rating main drive | 5 Hp |
| Overall dimensions (length x width x height) | 100x86x89 in |
| Weight | 3,498 lbs |
| Part No. | 301235 |
- More rigid and more powerful with 5 Hp motor
- ISO 40 spindle
- 3 automatic drill feeds
- Manual coarse feed for quill, with change-over for manual fine feed
- Quill with micrometer depth stop
- Reversing switch for forward reverse rotation
- Spindle brakes
- Infinitely variable speeds
- Head swivels 90 to the right and to the left
- TV 1000 table feed in X and Y, infinitely variable with rapid feed
- Coolant system
- Chip tray
- Central lubrication
- Pneumatic tool clamping
3-axis position indicator
- More accuracy
- Lower error rate
- Increased productivity
- Resulting in valuable time savings
- For increased productivity
- Easy to read display
- Operator-specific features
- Convenient keyboard layout
- Resolution: 0.0004 / 0.0002"
- Default coordinates
- Axis position is maintained when display is turned off
- Hole circle pattern calculation
- Calculator function
- Storage for 10 tools
- Radius / diameter toggle
- Mm/inch conversion
- Easy expansion and maintenance-free operation
- 3-axis position indicator
- table feed TV 1000 in X- and Y-axis
- pneumatic tool clamping
- chip tray
- coolant system
- central lubrication
- horizontal guideway cover
- operating tools
- operator manual
Get Your Price from Blumberg Machinery Co!
