Description
General Info Stock #: 211260021 Brand: Jones & Shipman Model: Suprema Easy 650 Year: 2007 Serial Number: S017434 Specifications Max Length Between Centers: 650 mm Center Height: 160 mm Max Diameter Ground: 300 mm Number Of OD/ID Spindles: 2/1 Workhead Speed: 1-600 RPM Wheelhead X-Axis Total Infeed: 260 mm M Wheelhead Swivel Range: 190 degree/ 45 degree External Grinding Wheels: 350 x 50 x 127 mm/ 300 x 25 x 127 mm Internal Grinding Wheel: 10-20 mm, 25-40 mm, 50-63 mm Equipped With Full Specs Available Upon Request
General Info
Stock #: 211260021
Brand: Jones & Shipman
Model: Suprema Easy 650
Year: 2007
Serial Number: S017434
Specifications
Max Length Between Centers: 650 mm
Center Height: 160 mm
Max Diameter Ground: 300 mm
Number Of OD/ID Spindles: 2/1
Workhead Speed: 1-600 RPM
Wheelhead X-Axis Total Infeed: 260 mm
M Wheelhead Swivel Range: 190 degree/ 45 degree
External Grinding Wheels: 350 x 50 x 127 mm/ 300 x 25 x 127 mm
Internal Grinding Wheel: 10-20 mm, 25-40 mm, 50-63 mm
Distance between centers 39-3/8", Height of centers 6-57/64", Max Swing over table 13-25/32", Max table travel 43.25", Traverse per rev of handwheel, coarse/fine.79/.097", Traverse speeds (variable).06-19", Min movement to reverse table 1/16", Max table swivel 9 deg, Dwell reversal, variable 0-5 sec, Max wheelslide ...more
