Description
Size 17 x 40
Accessory 1 Taper Attachment
Accessory 2 Collet Closer
Digital Readout Newall DP700
Swing Over Bed (In.) 17
Swing Over Cross Slide (In.) 11
Swing Through Gap (In.) 24 1/2
Length of Gap (In.) 7-2/3
Distance Between Centers (In.) 40
Spindle Bore (In.) 3-1/8
Spindle Mount D1-6
Spindle Taper with Sleeve MT-5
Number of Spindle Speeds 12
Range of Spindle Speeds (RPM) 36 - 1,800
Range of Longitudinal Feeds (IPR) 0.0015 - 0.04
Range of Cross Feeds (IPR) 0.00075 - 0.02
Number of Inch Threads 45
Range of Inch Threads (TPI) 2 - 72
Number of Metric Threads 39
Range of Metric Threads 0.2 - 14
Diametrial Pitch Threads Number 21
Diametrial Pitch Threads Range 8 - 44
Modular Pitch Threads Number 18
Modular Pitch Threads Range 0.3 - 3.5
Max Tool Size (In.) 1 x 1
Compound Slide Travel (In.) 6-2/7
Cross Slide Travel (In.) 9 1/4
Tailstock Spindle Travel (In.) 5
Taper in Tailstock Spindle MT-4
Follow Rest Capacity (In.) 1/2 - 3
Steady Rest Capacity (In.) 3/8 - 6-3/4
Width of Bed (In.) 12
Motor (HP) 7-1/2 HP, 230/460V, 3Ph
Ampearge Draw @ 230V 3Ph 22
Amperage Draw @ 460V 3Ph 11
Prewired (V.) 230
Coolant Pump Motor 1/8 HP
Weight (Lbs.) 3747
Overall Dimensions (L x W x H) (In.) 94 x 44 x 68
Drive Geared Head
Style (Type) Engine
Accessory 1 Taper Attachment
Accessory 2 Collet Closer
Digital Readout Newall DP700
Swing Over Bed (In.) 17
Swing Over Cross Slide (In.) 11
Swing Through Gap (In.) 24 1/2
Length of Gap (In.) 7-2/3
Distance Between Centers (In.) 40
Spindle Bore (In.) 3-1/8
Spindle Mount D1-6
Spindle Taper with Sleeve MT-5
Number of Spindle Speeds 12
Range of Spindle Speeds (RPM) 36 - 1,800
Range of Longitudinal Feeds (IPR) 0.0015 - 0.04
Range of Cross Feeds (IPR) 0.00075 - 0.02
Number of Inch Threads 45
Range of Inch Threads (TPI) 2 - 72
Number of Metric Threads 39
Range of Metric Threads 0.2 - 14
Diametrial Pitch Threads Number 21
Diametrial Pitch Threads Range 8 - 44
Modular Pitch Threads Number 18
Modular Pitch Threads Range 0.3 - 3.5
Max Tool Size (In.) 1 x 1
Compound Slide Travel (In.) 6-2/7
Cross Slide Travel (In.) 9 1/4
Tailstock Spindle Travel (In.) 5
Taper in Tailstock Spindle MT-4
Follow Rest Capacity (In.) 1/2 - 3
Steady Rest Capacity (In.) 3/8 - 6-3/4
Width of Bed (In.) 12
Motor (HP) 7-1/2 HP, 230/460V, 3Ph
Ampearge Draw @ 230V 3Ph 22
Amperage Draw @ 460V 3Ph 11
Prewired (V.) 230
Coolant Pump Motor 1/8 HP
Weight (Lbs.) 3747
Overall Dimensions (L x W x H) (In.) 94 x 44 x 68
Drive Geared Head
Style (Type) Engine
Get Your Price from Nevins Machinery Concepts Inc!
