For Sale by Victory Machinery Exchange
Surplus Record Dealer Since 1957
Location: Lake Forest, IL
Contact Neal Hoffenberg
Phone Number: 847...> Show Phone Number 847-918-9797
Let the seller know you found their listing on Surplus Record!
Description
Catalog Specs:
Wire Diameter: .059" (1.5mm) - .118” (3.0mm) Maximum Spring Diameter: .944" (24mm) Maximum Spring Length: 7.08" (180mm) Camshaft Characteristics: Min. Increment: Plus or Minus 0.05 Degrees Max. Increment: Plus or Minus 359.9 Degrees Max Speed: 200 rpm Wire Feed Characteristics: Min. Increment: .0007"(.02mm) Max. Increment 393" (9999.98mm) Max. Feed Speed: 295 ft/min" per min.(90 m/min)Slide Axis: Min. Increment: .001 Max. Increment 99.999 Max. Speed: 250 rpmMemory: 600 steps per program, Program Storage: 200 program 3.5" floppy diskPower: Wire Feed 5200W, Camshaft 5200W , Slide 400WPower Consumption: (200v/3/60): 25A Dimensions: 74" x77" x 45" HxWxD, Weight: 3527 lbs.
Equipped With:
Equipped with:5 T(4, 1), 1 C, 1 ?, Including One Servo Spinner and One Servo Slide2 U Attachments, Pneumatic Swing ArmRotary Quill, Servo Spinner, Servo Slide08278 hoursExtra Tooling & SlideTAK 2 Plane StraightenerFlat Screen, USB Drive, Manuals, No MPG (Remote)
Location: Lake Forest
Wire Diameter: .059" (1.5mm) - .118” (3.0mm) Maximum Spring Diameter: .944" (24mm) Maximum Spring Length: 7.08" (180mm) Camshaft Characteristics: Min. Increment: Plus or Minus 0.05 Degrees Max. Increment: Plus or Minus 359.9 Degrees Max Speed: 200 rpm Wire Feed Characteristics: Min. Increment: .0007"(.02mm) Max. Increment 393" (9999.98mm) Max. Feed Speed: 295 ft/min" per min.(90 m/min)Slide Axis: Min. Increment: .001 Max. Increment 99.999 Max. Speed: 250 rpmMemory: 600 steps per program, Program Storage: 200 program 3.5" floppy diskPower: Wire Feed 5200W, Camshaft 5200W , Slide 400WPower Consumption: (200v/3/60): 25A Dimensions: 74" x77" x 45" HxWxD, Weight: 3527 lbs.
Equipped With:
Equipped with:5 T(4, 1), 1 C, 1 ?, Including One Servo Spinner and One Servo Slide2 U Attachments, Pneumatic Swing ArmRotary Quill, Servo Spinner, Servo Slide08278 hoursExtra Tooling & SlideTAK 2 Plane StraightenerFlat Screen, USB Drive, Manuals, No MPG (Remote)
Location: Lake Forest
