For Sale by Machine Tool Technologies
Surplus Record Dealer Since 2011
Joe Ryan
414-48...> Show Seller's Phone Number 414-486-9700 Let the seller know you found their listing on Surplus Record!
Description
Spec Sheet
Technical Parameters
Tube processing range:
Round tube: φ20 - φ273
Square tube: □20*20 - □220*220
Rectangular tube: diagonal ≤254mm
Angle Steel: ≤8#(80x80mm)
Channel: ≤8#(80x43mm)
Optional claw:
Angle Steel: ≤18#(180x180mm)
Channel: ≤20#(180x70mm)
H Beam: ≤18#(180x180mm
Notice: All bevel cutting pipes should be above 40mm, wall thickness above 3mm.
Range of incoming materials for tube: 1000-9200mm
Positioning precision of X/Y axis: ±0.05 mm/m
Repetitive positioning precision of X/Y axis: ±0.03 mm
Speed of chuck: 140 RPM (When the tube weight increases, the motion parameters would be reduced correspondingly）
Max. linkage speed: 140 mm/m (When the tube weight increases, the motion parameters would be reduced correspondingly) Max. linkage acceleration: 1.4 G
Maximum single tube weight: About 300kg (33kg/m)
Tailing length: ≥220mm（straight cut,for bevel cutting machine double chuck clamping mode）
Machine Dimensions: About 16000×6400×2800mm
Bevel angle: ±45°
Bevel cutting surface: V, Y
Number of phases: 3
Rated voltage of power source: 380V
Frequency: 50/60Hz
Power/ Current: 65KW/130A (6000W)
Tube processing range:
Round tube: φ20 - φ273
Square tube: □20*20 - □220*220
Rectangular tube: diagonal ≤254mm
Angle Steel: ≤8#(80x80mm)
Channel: ≤8#(80x43mm)
Optional claw:
Angle Steel: ≤18#(180x180mm)
Channel: ≤20#(180x70mm)
H Beam: ≤18#(180x180mm
Notice: All bevel cutting pipes should be above 40mm, wall thickness above 3mm.
Range of incoming materials for tube: 1000-9200mm
Positioning precision of X/Y axis: ±0.05 mm/m
Repetitive positioning precision of X/Y axis: ±0.03 mm
Speed of chuck: 140 RPM (When the tube weight increases, the motion parameters would be reduced correspondingly）
Max. linkage speed: 140 mm/m (When the tube weight increases, the motion parameters would be reduced correspondingly) Max. linkage acceleration: 1.4 G
Maximum single tube weight: About 300kg (33kg/m)
Tailing length: ≥220mm（straight cut,for bevel cutting machine double chuck clamping mode）
Machine Dimensions: About 16000×6400×2800mm
Bevel angle: ±45°
Bevel cutting surface: V, Y
Number of phases: 3
Rated voltage of power source: 380V
Frequency: 50/60Hz
Power/ Current: 65KW/130A (6000W)
Equipped With
Water Chiller
Transformer & Voltage Stabilizer
Laser Source Cabinet
Safety Package
Dust Collector
Unloading Machine TS2-AU45-E
1 Seat of HSG Nesting Software
Multi Tube Auto Loading Machine R5AL01-9
Seam Detection
HSG Bevel Cutting Head
Consumables Package
Warranty
Transformer & Voltage Stabilizer
Laser Source Cabinet
Safety Package
Dust Collector
Unloading Machine TS2-AU45-E
1 Seat of HSG Nesting Software
Multi Tube Auto Loading Machine R5AL01-9
Seam Detection
HSG Bevel Cutting Head
Consumables Package
Warranty
Get Your Price from Machine Tool Technologies!
