Graf #Linear-Fab-5000, Profile Machining Center, 3500 mm L x 125 mm width x 130 mm H profile, 10 bars magazine load capacity, 2013

$273,865 USD

Request Formal Quote

GRAF LINEAR FAB 5000 CNC Automatic Machining Center For PVC And Aluminum Windows (Complete Line)German engineered CNC machining line with (5) controlled axes for PVC and aluminum (reinforcement) window production. Suited for large, high-production manufacturing environments and compatible with PVC profiles. For complete processing of PVC and aluminum window profiles. The machine performs the following processes in PVC and aluminum reinforcements: Drainage holes, air vents, holes for lock caps, holes for handles, marking for pressure plates, holes for lock striker plate, milling for gaskets, drilling for roller shutters, milling for forced ventilation, milling holes for fitting groove, drilling under the hinges on the frame and sash, cutting profiles and many more.PC-based control technology with LCD display type TFT and 10/100 MB network card. Process-reliable display of production and machine data with easy to operate intuitive menu navigation and the visual representation of machining processes on the touchscreen display. The Window Machining Line Is Made Up Of The Following (5) Equipment Components:GRAF "LINEAR FAB 5000" CNC Automatic Machining Center High performance CNC machining center with (5) controlled axes, designed for processing of PVC and aluminum (reinforcement) profilesSpecifications:(5) Drilling/milling units complete with high-frequency spindlesMax. profile dimensions: Length = 3500 mm; Width = 125 mm; Height = 130 mmMin. profile dimensions: Length = 350 mm; Width = 40 mm; Height = 40 mmMax. magazine loading cap.: (10) barsDimensions: 10500 x 2650 x 2050 mmWeight: 2850 kG (6270 Lbs)GRAF "SA 1000" Automatic Screwdriver GRAF "VK 2522" Bench For Assembly And GlazingVertical "bench" used to block the casement in a correct position to easily perform the following operations: Assembling the aluminium water condensation drains, Assembling the hinge(s), Assembling the window striker plate, Assembling the glass, Putting together the window casement and wings, Assembling the shutter with the window, Making the unloading operation of the complete window easier.GRAF "CUT 500P" Automatic Cutting Center CNC cutting center with controlled axes, specially devised for PVC profiles. The machine loads the profile from the bar magazine, cuts and unloads the finished piece fully independently, with no need of operator assistance. The machine is suitable for any type of profile for windows and doors Specifications: Ideal to produce (240) windows per 8-hour shiftMax. profile dimensions: Length = 6500 mm; Width = 130 mm; Height = 130 mmMin. profile dimensions: Length = 700 mm; Width = 40 mm; Height = 40 mmMax. loading magazine cap.: 10 - 12 barsDimensions: 1200 x 2200 x 1600 mmWeight: 2850 kG (6270 Lbs)GRAF "FMS 2430" Station For Installation Of HardwareTable for mounting hardware designed to enable quick installation. Suitable for all hardware systemsNOTE: The machines are in very good condition and ready for immediate delivery. NOTE: EX-FACTORY&rsquo
