For Sale by Gibbs Machinery Co
Surplus Record Dealer Since 1956
Location: Warren, MI
Contact Sales Dept.
Phone Number: 586...> Show Phone Number 586-755-5353
Let the seller know you found their listing on Surplus Record!
Description
Specifications:
Max. Diameter of Gear: 20"
Speed of Drive Spindle: 1200 rpm
Max. Offset of Gear Spindle Above or Below Center of Pinion Spindle: 3 1/2"
Max. Distance from Center of Gear Spindle to Nose of Pinion Spindle: 12"
Min. Distance from Center of Gear Spindle to Nose of Pinion Spindle: 4 3/4"
Max. Distance from Center of Pinion Spindle to Nose of Grear Spindle: 10 3/4"
(Hydraulic Machine has 3" Additional Movement for Withdraw of the Head)
Min. Distance from Center of Pinion Spindle to Nose of Gear Spindle: 3 1/2"
Belt (3 Required "V" Type): No. B75
Horse Power of Motor Required: 5
Floor Space: 53" x 59"
Net Weight (Approximately): 4,500 lbs
Max. Diameter of Gear: 20"
Speed of Drive Spindle: 1200 rpm
Max. Offset of Gear Spindle Above or Below Center of Pinion Spindle: 3 1/2"
Max. Distance from Center of Gear Spindle to Nose of Pinion Spindle: 12"
Min. Distance from Center of Gear Spindle to Nose of Pinion Spindle: 4 3/4"
Max. Distance from Center of Pinion Spindle to Nose of Grear Spindle: 10 3/4"
(Hydraulic Machine has 3" Additional Movement for Withdraw of the Head)
Min. Distance from Center of Pinion Spindle to Nose of Gear Spindle: 3 1/2"
Belt (3 Required "V" Type): No. B75
Horse Power of Motor Required: 5
Floor Space: 53" x 59"
Net Weight (Approximately): 4,500 lbs
Get Your Price from Gibbs Machinery Co!
