1 / 5
Click to zoom in
1 / 5
For Sale by Gibbs Machinery Co
Surplus Record Dealer Since 1956
Location: Warren, MI
Contact Sales Dept.
Phone Number: 586...> Show Phone Number 586-755-5353
Let the seller know you found their listing on Surplus Record!
Description
Specifications:
Strokes per Minute: 33 - 1300
Maximum Pitch Diameter (External): 10"
Maximum Pitch Diameter (Internal): 10"
Maximum Diametral Pitch (Spur): 4
Maximum Diametral Pitch (Helical): 5
Maximum Face Width 10-2: 2"
Maximum Helix Angle (Using 5" Cutter): 45 Deg
Maximum Overall Length: 118-7/8"
Maximum Overall Height (Zero Raise): 96-1/2
Maximum Overall Depth: 53"
Net Weight With Motors: 11,000 lbs
Strokes per Minute: 33 - 1300
Maximum Pitch Diameter (External): 10"
Maximum Pitch Diameter (Internal): 10"
Maximum Diametral Pitch (Spur): 4
Maximum Diametral Pitch (Helical): 5
Maximum Face Width 10-2: 2"
Maximum Helix Angle (Using 5" Cutter): 45 Deg
Maximum Overall Length: 118-7/8"
Maximum Overall Height (Zero Raise): 96-1/2
Maximum Overall Depth: 53"
Net Weight With Motors: 11,000 lbs
Get Your Price from Gibbs Machinery Co!
