For Sale by Machine Tool Technologies
Surplus Record Dealer Since 2011
Description
RESONATOR Watt YLR 4000
POWER RANGE % 10-105
LASER BEAM QUALITY @ COLLIMATOR mm mrad 1 - 2
POWER STABILITY % 1 - 3
PULSE FREQUENCY RANGE kHz 5
LASER WAVE LENGTH nm 1070 ± 5
OUTPUT FIBER CORE DIAMETER μm 150
COOLING WATER FLOW RATE Gallon/Min 2.1
CUTTING CAPACITY (High Quality)
MILD STEEL .797"
STAINLESS STEEL .47"
ALUMINUM .39"
BRASS .25"
COPPER .25"
MAXIMUM WORKSHEET DIMENSIONS
120" X 60"
MAXIMUM BURDEN CAPACITY pounds 3307
MACHINE AXES
4-Axes [X, Y, Z, U ]
Servo Motorized Table
inch
120
Y AXIS
ACCELERATIONS
Servo Motorized Table
MAXIMUM AXES VELOCITIES
POSITIONING ACCURACY inch ± 0,001
SHUTTLE TABLE (Automatic Loading - Unloading Unit)2 ( 35 sec )
ASSIST GAS
BECKHOFF CP6242
15-inch display 1024 x 768, alphanumeric keyboard, PLC keys on the sides, touch screen keyboard
AVARAGE POWER CONSUMPTION HP 23
MACHINE DIMENSIONS ( L x W x H ) inch 362 X 146 X 87
MACHINE WEIGHT pounds 24,690
POWER RANGE % 10-105
LASER BEAM QUALITY @ COLLIMATOR mm mrad 1 - 2
POWER STABILITY % 1 - 3
PULSE FREQUENCY RANGE kHz 5
LASER WAVE LENGTH nm 1070 ± 5
OUTPUT FIBER CORE DIAMETER μm 150
COOLING WATER FLOW RATE Gallon/Min 2.1
CUTTING CAPACITY (High Quality)
MILD STEEL .797"
STAINLESS STEEL .47"
ALUMINUM .39"
BRASS .25"
COPPER .25"
MAXIMUM WORKSHEET DIMENSIONS
120" X 60"
MAXIMUM BURDEN CAPACITY pounds 3307
MACHINE AXES
4-Axes [X, Y, Z, U ]
Servo Motorized Table
inch
120
Y AXIS
ACCELERATIONS
Servo Motorized Table
MAXIMUM AXES VELOCITIES
POSITIONING ACCURACY inch ± 0,001
SHUTTLE TABLE (Automatic Loading - Unloading Unit)2 ( 35 sec )
ASSIST GAS
BECKHOFF CP6242
15-inch display 1024 x 768, alphanumeric keyboard, PLC keys on the sides, touch screen keyboard
AVARAGE POWER CONSUMPTION HP 23
MACHINE DIMENSIONS ( L x W x H ) inch 362 X 146 X 87
MACHINE WEIGHT pounds 24,690
