For Sale by Smith Machinery Co
Surplus Record Dealer Since 2001
Description
Specifications
Equipped With
SPECIFICATIONS:
ACCURACY: MAXIMUM INDEXING ERROR ------- 0.0015 @ 10 in DIAM.
REPEATABILITY: ------------------------- LOW TEN-THOUSANDS OF AN INCH.
POSITIVE DOUBLE LOCK: ------------------ WHEN THE PART HAS BEEN INDEXED BY THE SPEED INDEXER, THE SPRING-LOADED TAPERED INDEX PIN ACCURATELY LOCATES ITS ANGULAR POSITION, AND AT THE SAME TIME LOCKS IT AGAINST FURTHER ROTATION OR MOVEMENT.
AVAILABLE INDEX POSITIONS: ------------- 4 TO 60 POSITIONS
ACTUATION: ----------------------------- THE SPEED INDEXER MAY BE ACTUATED IN THE CIRCUIT MANUALLY, ELEC-TRICALLY (WITH SWITCHING, PUSH- BUTTON, PROGRAMMING SWITCH, in M in FUNCTION OF TAPE CONTROL UNIT, ETC.) PILOT AIR, PILOT HYDRAULICS OR CAM.
MOUNTING POSITION: --------------------- THE STANDARD SPEED INDEXER MAY BE USED W/TABLE IN EITHER HORZ. OR VERTICAL POSITION WITH CONSTANT RIGIDITY. THIS PERMITS ITS USE W/INDEXING DRUMS, FACE-PLATE PART MOUNTING & MANY OTHER APPLICATIONS
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
DELIVERY:
IMMEDIATE, SUBJECT TO PRIOR SALE
