New Multi-Profile Machine Tube Processing Center.
Plasma Cut Round, Square, Rectangle, Angle, Channel, and Flat bar, all on one machine!
Miter cut, profile, and cope round and square materials up to 4.5 and up to 15 lbs/ft* by 24ft long, such as handrail. Burn holes, squares/rectangles, and slots all in one efficient process, reducing or eliminating costly manual measuring, sawing, drilling, and grinding.
With this machine, you will be cutting production parts within an hour of it hitting your floor.
Enjoy the speed of automating your metal-fab department for a very modest investment with the TPC 2444 EL-SQUARED.
| Cutting Capacity (Round) | to 4 Sch 80 at 15 lbs/ft | to 4 Sch 80 at 15 lbs/ft |
| Cutting Capacity (Square) | to 4 Sch 80 at 15 lbs/ft | to 4 Sch 80 at 15 lbs/ft |
| Cutting Capacity (Angle) | 4x 4x 1/2 or 13 lbs/ft | 4x 4x 1/2 or 13 lbs/ft |
| Cutting Capacity (Rectangle) | to 4 Sch 80 at 15 lbs/ft | to 4 Sch 80 at 15 lbs/ft |
| Cutting Capacity (Channel) | 4x 4x 1/2 or 13 lbs/ft | 4x 4x 1/2 or 13 lbs/ft |
| Cutting Capacity (Flat Bar) | 4x 4x 1/2 or 13 lbs/ft | 4x 4x 1/2 or 13 lbs/ft |
| Amps | 20 amps | 20 amps |
| Power Requirements | 220VAC 1ph | 220VAC 1ph |
| Control | CNC (Centroid CNC Control) | CNC (Centroid CNC Control) |
| Dimensions | 27x 4x 6 | 27x 4x 6 |
| Weight | 2,400lbs | 2,400lbs |
Material Shape - Round, Square, Rectangular, Angle Iron, C-Channel, FlatBar
Maximum Work Length - Loading: 24 and Unloading: up to 8
Material Diameter - Round, Square, Rectangle: to 4 Sch 80 at 15 lbs/ft
Angle Iron, C-channel, Flat bar: 4x 4x 1/2 or 13 lbs/ft
Axis Travel - X lengthwise: 296, Y crosswise: 9, Z up/down: 7 A, U: continuous rotation
Height of Chuck Center - 46
Maximum Material Thickness - Up to
*changes with torch selection*
Rapid Travel Speed - X axis: 1200/min *configurable* Y, Z axis: 500/min, A, U, axis: 21,600/min
Electrical Requirement - Control: 20 amps 220VAC 1ph
Torch: as per Hypertherm selection
Air Requirement - Control: 180 SCFH* with chiller
Torch: as per Hypertherm selection
Installation Dimensions - Minimum WxDxH: 6x 38x 7
CNC Type - Centroid
CPU - 64 bit
Display Screen - Single 20 LED
Number of Control Axes - 5
Servo System - Closed Loop Servo
Program Input System - Conversational and G-Code
Centroid CNC Hickory controller
Closed Loop Yaskawa Servo System
Dual Screen Monitor Station with keyboard/mouse
High-Temp Chassis/SSD Industrial PC/Windows IOT OS
Industrial Grade
WIFI/USB/Ethernet connections
Manual 4-Jaw Chuck
Air-Blast
Three Automatic Material Supports
Hypertherm 45amp* with Torch/CNC Interface, and a selection of Torch Consumables.
