Elumatec #SBZ-628XL, CNC profile machining center, 2022

$399,230 USD

Request Formal Quote

ELUMATEC SBZ 628 XL CNC Profile Machining Center SBZ 628 series offers ultimate flexibility in both machining and length cutting of aluminium profiles for metal construction and industrial applications. Its production reliability, speed, cost-effectiveness and impressive versatility make the flexible profile machining centre the perfect all-rounder. It allows fully automatic machining of various profile types, such as for windows, doors and curtain walls, using up to eight routing units that can operate freely on the profile cross-section in coordination with innovations such as travelling clamps and pivoting grippers. SBZ 628 XL: Pass-Through System For Windows, Doors And Curtain Walls ● Up to (8) spindles for routing or drilling ● [4] Axes sawing capability ● Different separating cut strategies from 22.5 to 157.5 and notching (pivoting) ● Quick-change systems for tension rollers and clamping plates for atypical profiles ● Mode for manual insertion and clamping of non-stationary profiles.Machine Configuration ● Left loading magazine for automatic production processes ● The routing spindles can be positioned continuously over 360 on the profile bar for machining profiles in various clamping situations ● A noise abatement enclosure and the easy-access controls and maintenance elements simplify operation ● Machined profiles are placed onto the unloading magazine ● Versions customized to meet specific customer requirements can be redesigned upon request Specifications: ● Max. bar length: 7600 mm ● Working direction: Right to Left or Left to Right (switchable) ● Max. profile cross-section: 320 x 160 / 160 x 320 mm ● Min. profile cross-section (depending on gripper position): 30 x 10 mm ● Finished part length: 350 - 7600 mm ● Max. Spindle speed: 24,000 RPMMachining Stations ● Axes: (5) ● Router spindles: 4 - 8 (servo-assisted)Feed Magazine: ● Shortest blank bar length: 1500 mm ● Number of swing arms: 5 (option for 9) ● Mounting positions: 10 (above 120 mm 5) ● Servo drive: Linear ● Motorized gripper adjustment: Y/Z ● Gripper rotation: Standard ● Residual piece measurement: Optional ● Residual piece processing: Fully AutomaticSawing Station ● Axes: (4) ● Saw blades dia.: 1 (550 mm), optional 650 mm ● Sawing angles: 22.5 - 157.5 (pivoting) ● Notching: Standard Outfeed Conveyor ● Lifting station: Yes ● Number of swing arms: 8 ● Outfeed conveyor width: 4,000 mm (can be extended)Equipped with: ● Tool changer for (11) tools (with 2 hardware tightening units) ● (2.) Milling Spindles (6 kW/8.04 hp) ● VHM Cutter Set ● Carbide Sawblade, Dia. 550 mm, T = 160 ● Carbide Sawblade, Dia. 650 mm, T = 188 ● Collet Chuck (HSK-C40) ER 32 for Collets 2 - 20 mm ● Collet Chuck (HSK-C40) ER 20 for Collets 1 - 13 mm ● Cooling device for control cabinet for tempera
