Model: 155-DS
Stock # 821300N
For Sale by RT Machine
Surplus Record Dealer Since 2025
Sales
570-58...> Show Seller's Phone Number 570-584-2002 Let the seller know you found their listing on Surplus Record!
Description
- Elcon Model 155 DS Vertical Panel Saw
- Ridged, welded box steel frame with three vertical cutting positions
- Round upper guide rail with concave bearings for smooth operation
- Equipped with panel transport rollers at base
- Segmented midway fence that is the full length of frame
- 3kw (~4hp) motor
- 10" blade capacity
- Double cut plunge scoring system
- Automatic moveable panel support grid
- Manual plunge of saw head
- Two pneumatic panel clamps
- Programmable rail for predetermined horizontal cuts
- Repeat rip guide
- Both English and metric scales standard
- Saw head is counter balanced with chain & safety chain
- 10" saw blade included
- Built-in dust shroud with pipe ready for dust collection
- Maximum Cutting Length 129"
- Maximum Cutting Height (hor) 59"
- Maximum Cutting Height (ver) 61"
- Overall length of machine 178"
- Overall height of machine 91"
- Overall depth of machine 57"
- Motor 3kw (4 hp), 3 phase
- Blade rpm 5100 rpm Weight Frame (1650)
Get Your Price from RT Machine!
