Manufacturer: Dn Solutions
Model: PUMA-MX2100ST
Year: 2022
Swing: 29.5
Chuck: 8
Bar Capacity: 2.6
Stock # 10068
Click to zoom in
For Sale by Used CNC LLC
Surplus Record Dealer Since 1997
Location: Huntley, IL
Contact Mike Oracko
Phone Number: 224...> Show Phone Number 224-537-0982
Let the seller know you found their listing on Surplus Record!
Description
2022 DN SOLUTIONS PUMA MX 2100ST
SPECIFICATIONS:
Swing Over Bed......................... 29.5"
Turning Diameter....................... 21.3"
Turning Length......................... 40.2"
Chuck Size 1........................... 8"
Spindle Nose 1......................... A2-6
Spindle Bore Diameter 1................ 3"
Bar Capacity 1......................... 2.6"
Spindle Speeds 1....................... 5,000 RPM
Spindle Horsepower 1................... 29.5 hp
Chuck Size 2........................... 8"
Spindle Nose 2......................... A2-6
Spindle Bore Diameter 2................ 3"
Bar Capacity 2......................... 2.6"
Spindle Speeds 2....................... 5,000 RPM
Spindle Horsepower 2................... 29.5 hp
B - Axis Head Travel................... 41.3
B - Axis Head Indexing................. 0.001
B - Axis Milling Spindle Taper......... Capto C6
B - Axis Milling Spindle Speed......... 12,000 RPM
B - Axis Milling Spindle Horse Power... 24.8 hp
ATC For Milling Spindle................ 30
Tool Diameter.......................... 3.5 / 4.7
Tool Length............................ 11.8"
Tool Weight............................ 19.8 lb
X1 - Axis Travel....................... 22.2"
X2 - Axis Travel....................... 7.4"
Z1 - Axis Travel....................... 41.3"
Z2 - Axis Travel....................... 41.3"
Y1 - Axis Travel....................... 6.7"
C - Axis Indexing 1.................... 0.001
C - Axis Indexing 2.................... 0.001
Rapid Traverse Rate - X1............... 1417 ipm
Rapid Traverse Rate - X2............... 945 ipm
Rapid Traverse Rate - Z1............... 1417 ipm
Rapid Traverse Rate - Z2............... 1417 ipm
Rapid Traverse Rate - Y1............... 1023 ipm
Turret Tool Positions 1................ 12 station
Turret Rotary Tool Speeds 1............ 5,000 RPM
Machine Weight......................... 26,456 lb
Dimensions............................. 190.9" x 99.4" x 110.4
EQUIPPED WITH:
FANUC 31IB PLUS CNC CONTROL
TOOL PRESETTER
COOLANT THRU SPINDLE
CHIP CONVEYOR
SPECIFICATIONS:
Swing Over Bed......................... 29.5"
Turning Diameter....................... 21.3"
Turning Length......................... 40.2"
Chuck Size 1........................... 8"
Spindle Nose 1......................... A2-6
Spindle Bore Diameter 1................ 3"
Bar Capacity 1......................... 2.6"
Spindle Speeds 1....................... 5,000 RPM
Spindle Horsepower 1................... 29.5 hp
Chuck Size 2........................... 8"
Spindle Nose 2......................... A2-6
Spindle Bore Diameter 2................ 3"
Bar Capacity 2......................... 2.6"
Spindle Speeds 2....................... 5,000 RPM
Spindle Horsepower 2................... 29.5 hp
B - Axis Head Travel................... 41.3
B - Axis Head Indexing................. 0.001
B - Axis Milling Spindle Taper......... Capto C6
B - Axis Milling Spindle Speed......... 12,000 RPM
B - Axis Milling Spindle Horse Power... 24.8 hp
ATC For Milling Spindle................ 30
Tool Diameter.......................... 3.5 / 4.7
Tool Length............................ 11.8"
Tool Weight............................ 19.8 lb
X1 - Axis Travel....................... 22.2"
X2 - Axis Travel....................... 7.4"
Z1 - Axis Travel....................... 41.3"
Z2 - Axis Travel....................... 41.3"
Y1 - Axis Travel....................... 6.7"
C - Axis Indexing 1.................... 0.001
C - Axis Indexing 2.................... 0.001
Rapid Traverse Rate - X1............... 1417 ipm
Rapid Traverse Rate - X2............... 945 ipm
Rapid Traverse Rate - Z1............... 1417 ipm
Rapid Traverse Rate - Z2............... 1417 ipm
Rapid Traverse Rate - Y1............... 1023 ipm
Turret Tool Positions 1................ 12 station
Turret Rotary Tool Speeds 1............ 5,000 RPM
Machine Weight......................... 26,456 lb
Dimensions............................. 190.9" x 99.4" x 110.4
EQUIPPED WITH:
FANUC 31IB PLUS CNC CONTROL
TOOL PRESETTER
COOLANT THRU SPINDLE
CHIP CONVEYOR
