Manufacturer: Mori Seiki
Model: NTX-1000-SZM
Year: 2019
Swing: 17.7
Chuck: 8
Bar Capacity: 2.5
Stock # 10323
Click to zoom in
For Sale by Used CNC LLC
Surplus Record Dealer Since 1997
Location: Huntley, IL
Contact Mike Oracko
Phone Number: 224...> Show Phone Number 224-537-0982
Let the seller know you found their listing on Surplus Record!
Description
The 2019 DMG MORI NTX 1000SZMCNC Multi-Tasking Center offers versatile performance with dual spindles, 10-station turret, and high-speed milling spindle on B - axis head. Features CELOS/Fanuc control, machine tool presetter and gantry unload system with parts conveyor, Weight: 19,800 lbs.
2019 DMG MORI NTX 1000 SZM
SPECIFICATIONS:
Swing Over Bed......................... 17.7"
Turning Diameter....................... 16.9"
Turning Length......................... 31.4"
Distance Between Spindles.............. 41.3"
Chuck Size 1........................... 8"
Spindle Nose 1......................... A2 - 6
Spindle Bore Diameter 1................ 2.9"
Bar Capacity 1......................... 2.5"
Spindle Speeds 1....................... 5,000 RPM
Spindle Horsepower 1................... 15 hp
Chuck Size 2........................... 8"
Spindle Nose 2......................... FLAT
Spindle Bore Diameter 2................ 1.9"
Bar Capacity 2......................... 1.5"
Spindle Speeds 2....................... 6,000 RPM
Spindle Horsepower 2................... 10 hp
B - Axis Head Travel................... + - 120 DEGREES
B - Axis Head Indexing................. 0.0001
B - Axis Milling Spindle Taper......... CAPTO C5
B - Axis Milling Spindle Speed......... 20,000 RPM
B - Axis Milling Spindle Horse Power... 12 hp
ATC For Milling Spindle................ 76
Tool Diameter.......................... 2.7", 5.1"
Tool Length............................ 8.2"
Tool Weight............................ 11 lb
X1 - Axis Travel....................... 15"
X2 - Axis Travel....................... 6.1"
Z1 - Axis Travel....................... 24.2"
Z2 - Axis Travel....................... 24"
Y1 - Axis Travel....................... 8.2"
C - Axis Indexing 1.................... 0.0001
C - Axis Indexing 2.................... 0.0001
Rapid Traverse Rate - X1............... 1574 ipm
Rapid Traverse Rate - X2............... 787 ipm
Rapid Traverse Rate - Z1............... 1968 ipm
Rapid Traverse Rate - Z2............... 1417 ipm
Rapid Traverse Rate - Y1............... 1574 ipm
Turret Tool Positions 1................ 10 station
Turret Rotary Tool Speeds 1............ 10,000 RPM
Turret Rotary Tool Horse Power 1....... 6.2 hp
Machine Weight......................... 19,800 lb
Control................................ CNC (CELOS W/ FANUC 31I-B5 CNC COLOR CONTROL)
EQUIPPED WITH:
CELOS FANUC 31I - B5 CNC COLOR CONTROLCON
TOOL PRESETTER FOR TOOL SPINDLE
CHIP CONVEYOR
HIGH PRESSURE COOLANT SYSTEM THRU B AXIS INTERFACE / CHIP BLASTER R-50
ETHERNET I / P
BAR FEED INTERFACE
WORKPIECE UNLOADER
GANTRY UNLOAD SYSTEM PARTS REMOVAL
PARTS CONVEYOR
LOWER TURRET MILLING CAPABILITY
AIRBLOW FOR CHUCK
MIST COLLECTOR INTERFACE
IN MACHINE PART PROBING
TECHNOLOGY SOFTWARE CYCLE 5 AXIS SIMULTANEOUS MACHINING
MANUAL PULSE GENERATOR
MULTI DRY FILTER
SIGNAL LAMP 4 COLORS
