DMG, Mori #DMC-160UDB Deckel-Maho, 60 automatic tool changer, 62.9" X, 49" Y, 39" Z, 12000 RPM, CT40, 2007

5-AXIS MACHINING CENTERS DECKEL MAHO DMC160U duoBLOCK SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: Used 2007 DECKEL MAHO DMG-DMC160U duoBLOCK 5-AXIS UNIVERSAL MACHINING CTR: Made in Pfronten, Germany This machine is capable of simultaneous 5-axis and 5-sided machining because of the universal swivel head which moves continuously between vertical and horizontal spindle positions. SIEMENS 840D SOLUTIONLINE 3D CNC Control with electronic handwheel -WORKING RANGE- -WORKING TABLE (2 PALLETS) AUTOMATIC PALLET CHANGER- NC rotary table clamping surface 49.21" X 39.37" (1,250 mm X 1,000 mm) -5TH AXIS MILLING SPINDLE- The A axis in the milling head of the DMC125FD permits machining operations involving negative angles required, for instance, for the production of impellers. The swivel range is 130 degrees(-120/+10 degrees) with 30 degrees beyond the horizontal position and 10 degrees past beyond the vertical position. -MAIN SPINDLE DRIVE- -FEED DRIVES- -60 POSITION TOOL CHANGER- -COOLANT PUMP- -COOLANT THRU THE SPINDLE- -WEIGHT- Machine weight with table and pallet changer Approx 91,840 lbs (41 tons) Load on machine base including 2 x workpiece weight 105,280 lbs (47 tons) -EQUIPPED WITH- Automatic pallet changer with 2 pallets total Clamping Hydraulic 2/4 Channels Universal Milling Head with controlled A Axis Infrared Measuring Probe Signal Lamp with 4 Colors Oil and Emulsion Mist Separator Cooling by air blast through spindle 3D Machining, 3D Tool Compensation Transmit Lateral Surface Transformation Compcad Compressor Function MCIS DNC Machine (SINDNC) 118 KVA Transformer
