DMG, Mori Deckel Maho #DMU-100P-DuoBlock, 40 automatic tool changer, 39.4" X, 39.4" Y, 39.4" Z, 18000 RPM, 2005

5-AXIS MACHINING CENTERS DECKEL MAHO DMU100P duoBLOCK SUBJECT TO AVAILABILITY, AND TERMS AND CONDITIONS FOLLOWING, WE OFFER FOR YOUR CONSIDERATION: One used 2005 DMG MORI DECKEL MAHO DMU100P duoBLOCK 5-Axis UMC: Made was made in Pfronten, Germany at DECKEL MAHO-Pfronten Heidenhain Millplus iT 3-D control with 15" TFT flat screen. Highlights: -Easy to operate -Contour programming -Measuring cycles -Fast batch processing -Increased operator comfort through familiar DIN-ISO programming -Clear layout of the graphic user-interface -DECKEL MAHO spindle sensor technology -DECKEL MAHO ATC (Application Tuning Cycle) Control is equipped with the following options: -Electronic handwheel -2nd processor card with Windows 2000 -Application Tuning Cycle ATC: ATC is a software option for easy tuning of the feed-drives at the press of a button. Machine operator can adjust the machining optimal speed or optimal precision. These 3 settings are available from anywhere within a workpiece program. Benefits are minimized machining times combined with maximum quality for the desired parameters. If necessary, parameters can be set in relation to workpiece weight. -WORKING RANGE- -MAXIMUM WORKPIECE DIMENSIONS- -NC ROTARY TABLE 4TH AXIS (C-AXIS)- 1 x T-slot 18 H7 (alignment groove, table centre) 8 x T-slot 18 H12 (clamping grooves) -NC CONTROLLED 5TH AXIS (UNIVERSAL MILLING HEAD, B-AXIS)- B axis - NC controlled range up to 190 degrees. From vertical position 0 degrees to the left -10 degrees (in direction of tool magazine) and to the right to horizontal position +180 degrees=3D190 degrees in total. -MAIN DRIVE- Tool clamping hydraulic/mechanical for draw bolt ISO/DIS 7388/II type B -FEED DRIVES- -40 POSITION TOOL CHANGER- Maximum tool diameter with no neighbouring empty pockets 3.15" (80 mm) -HEIDENHAIN GLASS SCALES X/Y/Z AXES DIRECT PATH MEASURING SYSTEM- -HEIDENHAIN ROTARY ENCODERS B/C AXES DIRECT PATH MEASURING SYSTEM- -EXTERNAL FLOOD COOLANT PUMP- -580 PSI COOLANT THRU THE SPINDLE CENTRE (FORM AD)- This is a full 4th axis with Direct Measuring System (Heidenhain encoder) -EQUIPPED WITH- Fully enclosed protection cabin Production Package consisting of: -Coolant tank 158 gallon (600 l) -Automatic coolant cleaning through paper band filter -580 PSI (40 bar) coolant thru the spindle centre (Form AD) -Rotating clear-view window (in cabin window) -Chip conveyor with interval control RENISHAW MP10 Infrared parts measuring probe BLUM Laser tool measuring-tool length, diameter & broken tool detection -Automatic retraction of the measuring unit in a protected housing. -Tool length and diameter measuring in horizontal/vertical position. Spray pistol with pump, 14.5 PSI/10.4 gallon/min pump performance APPROXIMATE WEIGHT 37050#
