For Sale by Yoder Machinery Sales
Surplus Record Dealer Since 1960
Location: Holland, OH
Contact Sales
Phone Number: 866...> Show Phone Number 866-692-8933
Let the seller know you found their listing on Surplus Record!
Description
SERIAL ................................. 311073H5V-1
MODEL .................................. 750-2
AREA OF TABLE .......................... 128" X 25"
SPINDLE SPEEDS ......................... (24) 14 TO 1400 RPM
LONGITUDINAL AND CROSS FEEDS ........... (32) 3/8 TO 90 IPM
VERTICAL HEAD FEEDS .................... (32) 3/16 TO 45 IPM
LONGITUDINAL TRAVEL .................... 72"
CROSS TRAVEL ........................... 18"
VERTICAL TRAVEL OF HEAD ON COLUMN ...... 24"
CENTERLINE OF SPINDLE TO TOP OF TABLE .. 3" MIN, 27" MAX
CENTER OF TABLE TO COLUMN .............. 13-3/4 TO 31-3/4"
RAPID TRAVERSE ......................... 150 IPM
TAPER IN SPINDLE ....................... #50 NS
FLOOR TO TABLE CENTER .................. 39-1/2"
OVER ARM SUPPORT ....................... YES
OUT BOARD TABLE SUPPORTS ............... YES
SNAP SET READERS ....................... YES
SPINDLE MOTOR .......................... 50 HORSEPOWER
FEED MOTOR ............................. 7-1/2 HORSEPOWER
MODEL .................................. 750-2
AREA OF TABLE .......................... 128" X 25"
SPINDLE SPEEDS ......................... (24) 14 TO 1400 RPM
LONGITUDINAL AND CROSS FEEDS ........... (32) 3/8 TO 90 IPM
VERTICAL HEAD FEEDS .................... (32) 3/16 TO 45 IPM
LONGITUDINAL TRAVEL .................... 72"
CROSS TRAVEL ........................... 18"
VERTICAL TRAVEL OF HEAD ON COLUMN ...... 24"
CENTERLINE OF SPINDLE TO TOP OF TABLE .. 3" MIN, 27" MAX
CENTER OF TABLE TO COLUMN .............. 13-3/4 TO 31-3/4"
RAPID TRAVERSE ......................... 150 IPM
TAPER IN SPINDLE ....................... #50 NS
FLOOR TO TABLE CENTER .................. 39-1/2"
OVER ARM SUPPORT ....................... YES
OUT BOARD TABLE SUPPORTS ............... YES
SNAP SET READERS ....................... YES
SPINDLE MOTOR .......................... 50 HORSEPOWER
FEED MOTOR ............................. 7-1/2 HORSEPOWER
Get Your Price from Yoder Machinery Sales!
