Caterpillar R1600H, Underground Mining Loader, 271 HP Cat C11 diesel engine, 12-ton payload, 5.5-7.7 yd bucket capacity, 105-gallon fuel tank

CATERPILLAR® R1600H Underground Mining Load Haul Dump (LHD) Loaders

FASTER. SMARTER. SAFER. The Cat® R1600H Underground Loader has a powertrain tuned specifically for speed on grade — mastering poor floor conditions and delivering maximum production in all speed ranges. The loader offers a number of safety features, from FOPS/ROPS certified cab and safety glass to the ability to incorporate autonomous operation. Thanks to the extreme durability designed into the structure,the R1600H can be productive through up to four rebuilds.

1. Multiple bucket options available including dump buckets, ejector buckets and bolt-together buckets, plus full range of Cat® Ground Engaging Tools (GET) to achieve best productivity while maximizing bucket life

2. Proven frame design for increased durability

3. Spread hitch design, which widens the distance between upper and lower hitch plates to distribute forces and increase bearing life 8 2 6 7 12 4 1 5 3 9 THE CAT® R1600H UNDERGROUND LOADER

4. Proven Z-bar loader linkage geometry, which generates powerful breakout force, and an increased rack back angle for better bucket loading and material retention

5. Aggressive hydraulic performance for machine responsiveness and improved loading times

6. Continuous focus on safety and comfort including ROPS/FOPS cabin with ergonomic layout, plus interior and exterior safety details

7. Color Multi-Purpose Display (CMPD) and cluster gauge modules placed in front of the operator, which makes it a more comfortable environment to view during operation

8. VIMS Gen3, which provides vital machine health information; combines Health Information Monitoring and VIMS capability in one ECM; provides wireless, GPS and 3G network connectivity capabilities

9. Operator Present System, which detects the absence of operator input and applies the park brake; neutralizes the steering, implements and transmission; and shuts down the engine 14 16 15 13

10. Efficient Cat C11 ATAAC engine for unequalled lugging force while digging, tramming and traversing steep grades; Tier 3 and Ventilation Reduction (VR) engines MSHA compliant and certified to Canmet

11. Flow-through Diesel Particulate Filter developed for the VR Engine, suitable for mine sites using 15ppm sulphur content fuel, and further reduces particulate matter by ~ 51%

12. Cat MineStar™, including Command for underground, managed through onboard electronics; available automation-ready from the factory

13. Cat electrical components, such as connectors, wiring harnesses and ECMs, designed to live in corrosive environments 14. Radiator guard that swings open to allow service access; high-efficiency radiator offered as optional cooling package

15. Ground-level access to all tanks, filters, lubrication points and compartment drains, which simplifies servicing and reduces regular maintenance time

16. Brake release and tow hook option that allows you to remove the machine and disengage the park brake if the machine must be towed
