Caterpillar 992C, Wheel Loader, 690 HP CAT 3412 diesel engine, 6.8' max lift, 15' bucket width

Caterpillar 992C Wheel Loader

• Engine:
• Model: 3412.
• Net Power: 690 hp/514.5 kw.
• Displacement: 1647.6 cu in 27 L.
• Operational:
• Operating Weight: 187789.8 lb/85180 kg.
• Fuel Capacity: 300.1 gal/1136 L.
• Hydraulic System Fluid Capacity: 142.9 gal/541 L.
• Static Tipping Weight: 106483.3 lb/48300 kg.
• Transmission:
• Number of Forward Gears: 3.
• Number of Reverse Gears: 3.
• Max Speed – Forward: 13.1 mph 21.1 km/h.
• Max Speed – Reverse: 14.5 mph 23.3 km/h.
• Hydraulic System:
• Raise Time: 12 sec.
• Dump Time: 2.5 sec.
• Lower Time: 4 sec.
• Bucket:
• Breakout Force: 147050 lb/kN.
• Dump Clearance at Max Raise: 14.8 ft in 4496 mm.
• Bucket Width: 15.1 ft in 4597 mm.
• Bucket Capacity – heaped: 12.6 yd3 9.6 m3.
• Bucket Capacity – struck: 10.7 yd3 8.2 m3.
• Dimensions:
• Length with Bucket on Ground: 41.7 ft in/12720 mm.
• Height to Top of Cab: 28.7 ft in/8740 mm.
• Reach at Max Lift and Dump: 6.8 ft in/2083 mm.
• Location: England.
