150 Ton, Bystronic #Xpert-150, CNC Press Brake, 10' overall, 108.27" between housing, 8.49" stroke, 15.75" throat, 19.69" open, 41.34" BG

Tonnage: 155 US tons

Bending length: 122.05 in. (10' 2.05")

Standard stroke: 8.46 in.

Open height: 19.69 in.

Distance between the side stands: 108.27 in. (9' 0.27")

Throat: 15.75 in.

Table width: 2.36 in.

Max. backgauge range in X (2/4/5 axes): 41.34 in.

X-axis travel (2/4/5 axes): 23.62 in.

X-axis speed (2/4/5 axes): 25.59 in./s

X-axis accuracy (2/4/5 axes): ±0.0016 in.

R-axis travel (2/4/5 axes): 9.84 in.

R-axis speed (2/4/5 axes): 7.87 in./s

R-axis accuracy (2/4/5 axes): ±0.0039 in.

Z-axis travel: 74.80 in.

Z-axis speed (4/5 axes): 59.06 in./s

Z-axis speed (6 axes): 47.24 in./s

Z-axis accuracy (4/5 axes): ±0.0039 in.

Max. Y-rapid traverse: 7.87 in./s

Max. Y-approach speed in High Speed*: 8.66 in./s

Max. Y-working speed: 0.394 in./s

Max. Y-working speed in High Speed*: 0.787 in./s

Max. Y-working speed in High Speed for robot operation*: 0.787 in./s

Accuracy: ±0.00016 in.

Oil capacity: 79.3 gal.

Main motor power: 14.8 HP

Weight: 21,605 lb.

Preliminary Specifications - Subject to Verification
