For Sale by Machine Tool Technologies
Surplus Record Dealer Since 2011
Location: Milwaukee, WI
Contact Joe Ryan
Phone Number: 414...> Show Phone Number 414-486-9700
Let the seller know you found their listing on Surplus Record!
Description
Spec
Standard working area 10′ x 5′ (3050 x 1550 mm)
Optional working area 13′ x 6.5′ (4000 x 2000 mm) / 20′ x 6.5′ (6100 x 2050 mm) / 26′ x 6.5′ (8000 x 2000 mm)
Optional Laser Wattage 1500W / 3000W / 6000W
X-axis distance 120″ (3050 mm)
Y-axis distance 61″ (1550 mm)
Tube X1-axis distance 59″ (1500 mm)
Tube A, B axis distance Infinite rotation
Tube diameter Standard: 0.78″–8.66″ (20–220 mm)
Z-axis distance 11.8″ (300 mm)
X, Y two-axis coordinated positioning speed (MAX) 140 m/min
Positioning acceleration (MAX) 1.5 G
Positioning accuracy ±0.05 mm/m
Re-positioning accuracy ±0.02 mm
Maximum sheet load weight 700 kg (1543 lbs)
Maximum pipe load weight Auto-loading: 100 kg (220 lbs) / Manual-loading: 200 kg (440 lbs)
Laser resonator IPG
Laser head Raytools: 1.5–4 KW / Precitec: 6 KW
Controlling system Cypcut
X-Y-Z Servo Motors: X-2x2900W; Y-1x850W; Z-1x750W
Machine body weight Approximately 7000 kg (15,432 lbs)
Pipe rotation weight Approximately 1000 kg (2204 lbs)
Exchanging shuttle tables & auxiliary weight Approximately 2500 kg (5511 lbs)
Dimension no pipe cutting: 350″ x 118″ x 80″ (8900 x 3000 x 2050 mm)
Dimension with pipe cutting: 429″ x 142″ x 80″ (10,900 x 3600 x 2050 mm)
Description
Brand: BESCUTTER
Model: FLY PRO 3015
Type: Laser Cutters
Control: CNC
Year: 2023
Condition: Used – Excellent
Get Your Price from Machine Tool Technologies!
