For Sale by Adams Machinery
Surplus Record Dealer Since 1924
Location: Libertyville, IL
Contact Mark Sonneborn
Phone Number: 847...> Show Phone Number 847-673-0556
Let the seller know you found their listing on Surplus Record!
Description
SPECIFICATIONS
EQUIPPED WITH
EQUIPPED WITH:
Single Thread Index.
8” 3-Jaw Chuck.
Tailstock.
Rapid Traverse and Jog to the Hob Slide.
Trabon Lubrication System.
Coolant System.
| Maximum Rated Diameter Pitch (Nominal) | 6DP (4.2 Module) |
| Maximum Rated Work Diameter | 16” |
| Maximum Hob Diameter | 5” |
| Maximum Hob Slide Travel | 36” |
| Maximum Work Slide Travel | 8” |
| Main Drive Motor | 5HP |
| Approximate Dimensions | 108” x 48” x 76” Height |
| Approximate Weight | 7,000 lbs. |
EQUIPPED WITH
EQUIPPED WITH:
Single Thread Index.
8” 3-Jaw Chuck.
Tailstock.
Rapid Traverse and Jog to the Hob Slide.
Trabon Lubrication System.
Coolant System.
Get Your Price from Adams Machinery!
