Description
MAXIMUM NOMINAL DIAMETERAL PITCH............................: 6 DP
MAXIMUM DIAMETER OF WORK....................................: 16"
MAXIMUM HOB DIAMETER........................................: 5"
MAXIMUM HOB-SLIDE TRAVEL....................................: 16"
MAXIMUM WORK SLIDE TRAVEL...................................: 8"
MAXIMUM DISTANCE WORK SPINDLE TO HOB SPINDLE CENTERLINE.....: 8.75"
MINIMUM DISTANCE WORK SPINDLE TO HOB SPINDLE CENTERLINE.....: 0.75”
MAXIMUM DISTANCE WORK SPINDLE FACE TO TAILSTOCK-CENTER......: 44"
WORK SPINDLE THRU-BORE DIAMETER.............................: 4.13"
HOB SPEED RANGE.............................................: 59 TO 425 RPM
FEED RANGES.................................................: 0.015 TO .150 I.P.R.
MAIN DRIVE MOTOR............................................: 5 HP/1800 RPM
RAPID TRAVERSE HORSEPOWER...................................: 2
COOLANT PUMP HORSEPOWER.....................................: 1/4
LUBRICATION PUMP............................................: 1/20 HP
FLOOR SPACE.................................................: 90”X 82"
MACHINE OVERALL HEIGHT......................................: 84”
APPROX. MACHINE NET WEIGHT..................................: 7,600 LBS.
MAXIMUM DIAMETER OF WORK....................................: 16"
MAXIMUM HOB DIAMETER........................................: 5"
MAXIMUM HOB-SLIDE TRAVEL....................................: 16"
MAXIMUM WORK SLIDE TRAVEL...................................: 8"
MAXIMUM DISTANCE WORK SPINDLE TO HOB SPINDLE CENTERLINE.....: 8.75"
MINIMUM DISTANCE WORK SPINDLE TO HOB SPINDLE CENTERLINE.....: 0.75”
MAXIMUM DISTANCE WORK SPINDLE FACE TO TAILSTOCK-CENTER......: 44"
WORK SPINDLE THRU-BORE DIAMETER.............................: 4.13"
HOB SPEED RANGE.............................................: 59 TO 425 RPM
FEED RANGES.................................................: 0.015 TO .150 I.P.R.
MAIN DRIVE MOTOR............................................: 5 HP/1800 RPM
RAPID TRAVERSE HORSEPOWER...................................: 2
COOLANT PUMP HORSEPOWER.....................................: 1/4
LUBRICATION PUMP............................................: 1/20 HP
FLOOR SPACE.................................................: 90”X 82"
MACHINE OVERALL HEIGHT......................................: 84”
APPROX. MACHINE NET WEIGHT..................................: 7,600 LBS.
| Specifications | |
| Machine Type... | ...Gear Hobbers |
| Manufacturer... | ...BARBER COLMAN |
| Model... | ...16-16 |
| Year... | ...N/A |
| Condition... | ...Used |
