Atrump #KL2180, 21" swing, 80" between centers, coolant, 10 HP, new

Manufacturer Atrump
Model KL2180
Swing 21.0"
Stock # SMKL2180
Price $59,655

For Sale by Sterling Machinery Exchange

Platinum Level Dealer
Surplus Record Dealer Since 1970

Description

DETAILED SPECIFICATION
Overall Capacity21" x 80"
.
Height of Center10.53"
Swing Over Bed21"
Swing Over Cross Slide12"
Distance Between Centers80"
Width of Bed Ways13.78"
SPINDLE
Spindle Nose MountingSTD: D1-8
Spindle BoreSTD: 3-3/8"
Taper of Spindle BoreMT #7 (Sleeve MT #5)
Range of Spindle SpeedsAuto Shift High - Middle - Low
Longitudinal Travel (Z Axis)70.86"
Cross Slide Travel (X Axis)11.6"
Rapid Travel/Cutting Feed Rate270/120 ipm
Tool
Max. Size Cutting Tool1 " (4 Way Tool Post)
TAILSTOCK
Quill Diameter2.5"
Quill TaperMT #5
Quill Travel7"
Coolant Tank Capacity6 Gallons
WarrantyOne Year Limited Warranty
Horsepower10 H.P.
Voltage208V to 230V (Max) ~ 3 Phase
Dimensions (L x W x H)136" x 74" x 77"

EQUIPPED WITH
Centroid T400i Control with 15" Color LCD
10 H.P. Spindle Motor, D1-8, 3-3/8" through Hole Spindle
Max. 2000 rpm Spindle Speed with Auto Shift 3 Gear Range
Hardened & Ground with Turcite-B Coating Guide Way
C5 Double Nut Precision Ball Screws Hardened & Ground for High Accuracy & Long Lasting
FC30 Mechanite Casting Main Frame with Annealed & Stressed Relieved for Long Term Reliability
100% Laser Tested for Positioning Accuracy & Repeatability
Massive One Piece Casting Construction for Maximum Cutting Performance
14" Wide Bed Ways Designed to Provide Maximum Rigidity & Stability
Coolant System
Central Lubrication System
Built-In Quartz Work Light
Dual Hand Wheel for Manual Operation
USB 2.0 Port
RS-232 Interface
60 GB Solid State Hard Drive
Leveling Bolts & Plate
Full Guarding
Shop Floor Programming/Conversational
Spindle Nose 3-3/8"
Tool Box & Tools
Operation Manual
