Description
Specifications:
Width Capacity: 72"
Yield Strength: 50,000 PSI at .500" - .062" Thickness
Yield Strength: 90,000 PSI at .375" Thickness
Number Of Rolls: 9
Work Roll Diameter: 8"
Roll Face: 78"
Speed: Same as Existing Leveler
Flattener:
Configuration: 4 Over 3 Roll
Pinch Rolls: 2
Flex Roll: Between Pinch Rolls
Roll Drive: All Rolls Driven
Drive Components: Heavy Universals and Enclosed Gears Running in Oil
Screwdowns: Hydraulically Actuated Anti-Friction Screwdowns With Indicators
Roll Adjustment: Individual Roll Adjustment for Removing Coil Set and Cross Bow
Motor:
Type: Hydraulic or DC Variable Speed
Hydraulics:
Hydraulic Pump & Tank Unit: Included
Hydraulic Valves for Roll Adjustments: Included
72" 9 8" 78"
Width Capacity: 72"
Yield Strength: 50,000 PSI at .500" - .062" Thickness
Yield Strength: 90,000 PSI at .375" Thickness
Number Of Rolls: 9
Work Roll Diameter: 8"
Roll Face: 78"
Speed: Same as Existing Leveler
Flattener:
Configuration: 4 Over 3 Roll
Pinch Rolls: 2
Flex Roll: Between Pinch Rolls
Roll Drive: All Rolls Driven
Drive Components: Heavy Universals and Enclosed Gears Running in Oil
Screwdowns: Hydraulically Actuated Anti-Friction Screwdowns With Indicators
Roll Adjustment: Individual Roll Adjustment for Removing Coil Set and Cross Bow
Motor:
Type: Hydraulic or DC Variable Speed
Hydraulics:
Hydraulic Pump & Tank Unit: Included
Hydraulic Valves for Roll Adjustments: Included
