For Sale by Nidec Press & Automation
Description
Tonnage / Capacity 60 Metric Tons 66 US Tons
Stroke Length 120 mm 4.72 in
Speed 45-90 SPM
Area of Slide R-L x F-B 500 x 360 mm 19.69 x 14.17 in
Area of Bolster R-L x F-B 900 x 500 mm 35.43 x 19.69 in
Shutheight, Maximum (SDAU) 310 mm, on Bolster 12.2 in, on Bolster
Shutheight Adjustment 75 mm 2.95 in
Equipped With
STANDARD FEATURES
· Frame
o Machined for Strain Links (Tonnage Monitor)
o Drilled Provision for Knock Out Mechanism
o Able to Accept Air Cushions
o Pre-Drilled and Tapped to Accept Light Curtain
· Drive Train features a low inertia design with the gears running in a totally enclosed oil reservoir
· High-Performance Wet Clutch and Brake Air Actuated Combination Clutch and Brake
· Automatic Recirculating Oil Lubrication System
· Powered Die Height Adjustment & Electronic Die Height Indicator
· Air Counterbalance System
· Automatic Oil Lubrication System for Air Counterbalance Cylinders
· Hydraulic Overload Protection
· Die Safety Block
· Vibration Isolation Mounts
· Die Area Lights (2)
· PC3 Clutch/Brake & Electrical Control System
o Programmable Limit Switch (8)
o Die Protection (8)
o 30 Job Storage memory
OPTIONAL
Built-in Tonnage Monitor
Light Curtains
Servo Feeds
Custom Bolster Machining
Quick Die Change
Automation Systems
Automatic Shutheight
Automatic Counterbalance
