6" x 6" x 3/8" Uni-Hydro #56-24, 3-Station Hydraulic Ironworker, 56 Ton, 9" throat, 50 SPM, 5 HP

Description

Uni-Hydro 56 Ton 3-Station Hydraulic Ironworker, 56-24

Inventory # 10102

Model: 56-24

S/N: 3P561501X

Made in USA

Specifications:

Throat Depth: 9″

Tonnage: 56 Tons

Punch: 1 3/8″ Hole in 1/2″, 2 1/4″ Hole in 5/16″

Bar Shear: 1/2″ x 24″

Optional Angle Shear 90°:

Slug Type: 6″ x 6″ x 3/8″

Sever Cut: 4″ x 4″ x 3/8″

Miter Angle 45°:

Optional Slug Type: 4″ x 4″ x 3/8″

Optional Channel Shear: 2″ & 3″ Combined, 4″ Standard

Optional Rod Shear: 1 1/4″ Max. (Round and Square)

Optional Coper Notcher 90°: 4″ x 4″ x 3/8″

Optional Square Notcher: 2″ x 3″ x 3/8″, 3″ x 3″ x 3/8″

Optional Pipe Notcher: 1/2″, 3/4″, 1″, 1 1/4″, 1 1/2″, 2″

Optional Brake: 6″, 9″, 14″, 18″, 24″ Capacity

Strokes per Minute:

Light Material: 50 SPM

Max. Capacity: 9 SPM

Bar Shear Work Height: 29″

Punch Table Top Height: 39 1/4″

Cavity Table Top Height: 41″

Motor: 5 HP

Standard Features:

24″ bar shear with 4-sided blades

Bar shear hold-down can be fixed or adjustable

Magnetic starter for safety and reliability

Full up and down stroke control

Built for forklift handling

Manual punch aligner

Optional Tooling:

Punch Station:

Square Notcher

Coper Notcher

Pipe Notcher

6″ Brake

Power Cavity:

Angle Shear

Z & T Shear

Channel Shear

Brake: 6″ or 9″

Rod Shear (Round or Square)

Mechanical Specifications:

Dimensions: 46″ x 37″ x 70″ H

Weight: approx. 2,700 lbs.

New Replacement Cost: $20,000.00

FOB Our Baltimore, MD Warehouse

Please Note: Specifications are Listed to Show the Machine’s Capabilities. Some Applications and Processes Require Optional Tooling
