For Sale by Bud's Machine Tools
Description
Specifications
Bending Force 550 US tons
Bending Length 25′
Clear Pass 21'
Open Daylight 23.62"
Ram Stroke 14.76"
Table Size 10" x 25'
Throat Depth 21.65"
Close Height 8.85"
X-Axis Travel 23.62"
Dimensions 26'L x 11'W x 14'H +PIT
Equipped With
Servo Drive Motor for Hydraulic Power Pack Included
Front Cylinder Design Included
Selection of Auto, Inch & Single Cycle Auto thru screen Included
Servo Hydraulics from Atos/Hawe for Y1-Y2 control Included
Linear guided type press brake scale for Y1-Y2 axis position measurement Included
AC servo drive for X axis control Included
X-Axis Servo Back Gauge Included
Back gauge assembly includued ball screw drive unit, rotary encoder & LM guides Included
Extra Upper Tooling Beam allowing Customer to us other tooling and Clamps Included
Sliding sheet support (2 Nos Mounted on L.M. Guides Included
Manual Crowing
Get Your Price from Bud's Machine Tools!
