55" DN Solutions #VTR-1216FM, CNC vertical turret lathe w/ milling, 63" swing, 37.4" turning height, 15 ATC, 400 RPM, 60 HP, Fanuc I, 2022

Enhance your operations with this 2022 Doosan VTR 1216FM CNC Vertical Turning & Milling Center. Features a 49.2" table, 63" swing, and 60 HP main motor. Comes complete with FANUC CNC control and tooling package. Machine weight: 77,000 lbs. Act now!
2022 DN SOLUTIONS VTR 1216FM
SPECIFICATIONS:
Table Diameter.............. 55"
Table Load Capacity......... 17,636 lb
Swing Diameter.............. 63"
Turning Height.............. 37.4"
Table Speed................. 400 RPM
Main Motor.................. 60 hp
X - Axis Travel............. 67"
Z - Axis Travel............. 35.4"
Rapid Traverse Rate - X..... 472 ipm
Rapid Traverse Rate - Z..... 393 in/min.
C - Axis Indexing........... .001
Ram Size.................... 10.2" X 10.2"
Rotary Spindle Speed........ 3,000 RPM
Rotary Spindle Horsepower... 24.8 hp
Automatic Tool Changer...... 15
Machine Weight.............. 51,700 lb
Control..................... CNC (DOOSAN FANUC SERIES I CNC CONTROL)
Weight...................... 60000.00
EQUIPPED WITH:
FANUC SERIES I CNC PLUS CONTROL
15" COLOR CRT
EMBEDDED ETHERNET
2 MB PROGRAM STORAGE (5120 METERS)
STORED PITCH ERROR COMP
TOOL LOAD MONITORING
EASY PROGRAMMING GUIDE FOR PC (SKETCH TURN FOR PC)
EASY GUIDE I CONVERSATIONAL PROGRAMING
BIG PLUS MILLING SPINDLE
TELESCOPIC GUARDS & COOLANT SHEILDS
AUTO TOOL SETTER
AUTO POWER OFF
AIR CONDITIONER
CHIP CONVEYOR
ALL MANUALS
FULL STANDARD TOOLING PACKAGE
90 DEGREE RIGHT ANGLE HEAD (HIGH TORQUE)
COOLANT THRU THE MILLING HEAD
COOLANT GUN
55" INCH COMBINATION CHUCK (Seoam CAS-55)
DUAL PRESSURE CHUCKING
3434 ON HOURS
93 CUTTING HOURS
