500 Ton, Carrier #23XRV5556NRAA50-S, Water-Cooled Chiller, R-134a, Oil-free centrifugal compressor, 2012

Overview
For sale is a Carrier 23XRV Series Water-Cooled Centrifugal Liquid Chiller, model 23XRV5568NRAA50-8, featuring oil-free magnetic bearing technology for ultra-efficient performance. This unit was manufactured in 2012 and is ideal for large commercial or industrial HVAC applications.
Key Specifications
- Model: 23XRV5568NRAA50-S
- Serial Number: 4912027226
- Capacity: 500 Tons
- Refrigerant: R-134a (Factory Charge: 1200 lbs / 580 kg)
- Voltage: 460V / 3 Phase / 60 Hz
- Compressor Type: Oil-free centrifugal
- Design Pressure:
- Cooler: 186 PSIG
- Condenser: 186 PSIG
- Oil: 250 PSIG
- Test Pressure:
- Cooler: 280 PSIG
- Condenser: 280 PSIG
- Oil: 300 PSIG
Electrical Specs
- Locked Rotor Amps: 705 A
- Overload Trip Amps: 366 A
- Max Fuse/Breaker Size: 700 A
- MCA (Min Circuit Ampacity): 444 A
- Motor Nameplate HP: 480V
- Compressor Full Load Amps: 366 A
- Oil Pump: 115V, 1.4A / 500W
- Oil Sump Heater: 115V, 0.9A
- Oil Vaporizer Heater: 115V, 10.4A, 1500W
Certifications
- AHRI Certified
- UL Listed – Self-contained liquid chiller
- Assembled in USA – Charlotte, North Carolina
Condition
- Year of Manufacture: 2012
- Used, professionally maintained
- Sold as-is
Applications
- Large commercial buildings
- Industrial cooling systems
- Hospitals and data centers
- Central chilled water plants
Location: Ohio
