40000 PPH Cleaver-Brooks #NOS-1A-53, 350 psi, trailer mounted, lox NOx Natcom boiler

Details / Specifications
40,000 lb/hr O-Type Watertube Boiler 350 PSI Design
Manufacturer Cleaver Brooks / Nebraska Boiler
Model NOS-1A-53
Year Built 2008 and Newer
Burner Manufacturer NATCOM or COEN/TODD
Steam Capacity (PPH) 40000
Code Design
Built in accordance with ASME Code and bearing National Board stampings. Includes burner with NEMA IV construction for weather-tight outdoor installation. Includes All Canadian CRN.
Transformer
1/60/110V control circuit transformer, and is IRI, FM and NFPA approved
Control System
Allen Bradley PLC Burner Management System
Design Pressure (PSIG) 350
Dimensions 52'-4\ L x 8'-6"W x 13'-9\"" H"""
Drum Type O Type Boiler
Fan Type Forced draft fan with 50 or 75 HP TEFC motor 3/60/480V, 1800RPM; Windbox Mounted
Flame Monitoring System
Fireye microprocessor flame monitor system
Freight Method Trailer
Fuel Natural Gas / Oil
NOx With FGR 30 PPM
Operating Pressures 125 -335 PSIG
Starting System TEFC motor with starter
Steam Type Saturated
Steam Temp Up to 430 F At Saturation
Weight 73,000 lbs
More Info
Built in accordance with ASME Code and bearing National Board stampings. Includes burner with NEMA IV construction for weather-tight outdoor installation. It includes a free standing forced draft fan with 50 or 75 HP TEFC motor 3/60/480V, 1800RPM. Also included: Allen Bradley PLC burner management system, 1/60/110V., F.M and U.L. approved, and CSA listed, annunciator, fuel train and Allen Bradley microprocessor combustion control system, and fan inlet damper for fuel/air control and Fisher control valve for feedwater control.

Request More Information from Seller
