Manufacturer: Minster
Model: 90-400
Ton: 400
Stroke: 3.00
Shut Height: 15.50
Air Clutch: Yes
Stock # 90-400-KJ-UJ
1 / 5
Click to zoom in
1 / 5
For Sale by Westway Machinery Ltd
Surplus Record Dealer Since 1978
Location: Mississauga, ON Canada
Contact Sales Dept.
Phone Number: 905...> Show Phone Number 905-803-9999
Let the seller know you found their listing on Surplus Record!
Description
- Air Clutch + Brake
- Removable Ram Plate (2”)
- MODEL: 90-400
- ITEM ID: 90-400-KJ-UJ
- CAPACITY: 400 TON
- SERIAL#: N/A
- STROKE LENGTH: 3"
- SPEED: 30 SPM
- DIE HEIGHT (SDAU): 15.5"
- DIE HEIGHT ADJUSTMENT (MOTORIZED): 1/2"
- SLIDE AREA (L-R, F-B): 15" x 20"
- BED AREA (L-R, F-B): 20" X 22"
- BOLSTER THICKNESS: 2.25"
- WEIGHT: 25,000 LBS APPROX.
- DIMENSIONS (LxWxH): 75" X 75" X 134"
- LOCATION: OHIO, USA
