SPECIFICATIONS:
MAX CAPACITIES:
ROUND TUBING -------------- 90° = 4-1/2 in & 45° = 4 in
ROUND SOLID --------------- 90° = 2 in & 45° = 1 3/4 in
SQUARE TUBING ------------- 90° = 4 1/4 in x 4 1/4 in & 45° = 4 in x 4 in
SQUARE SOLID -------------- 90° = 2 in x 2 in & 45° = 1 3/4 in x 1 3/4 in
RECTANGLE TUBING ---------- 90° = 5 1/2 in x 4 in & 45° = 3 3/4 in X 3 3/4 in
MITER CAPABILITIES ---------- 45° LEFT TO 45° RIGHT
MITER LOCKING DEVICE -------- STOPS @ 45° L, 90° & 45° R
TWO CUTTING SPEEDS
LT ------------------------ 22/44 RPM
HT ------------------------ 44/88 RPM
ELECTRICS ------------------- 230 OR 460V / 3 PHASE (MUST SPECIFY VOLTAGE)
EQUIPPED WITH:
* AIR OPERATED DOUBLE SELF-CENTERING VISE-BURR FREE CUTS.
* PNEUMATIC POWER DOWN FEED WITH ELECTRIC CONTROLS.
* EMERGENCY STOP BUTTON.
* CAPABLE OF SLOTTING.
* DOUBLE REDUCTION, HARDENED AND GROUND WORM & WHEEL GEAR BOX.
* WORM WHEEL OF TOP QUALITY BRONZE.
* CHIP DRAWER.
* SEVEN GALLON COOLANT TANK WITH PUMP.
* ONE 315MM DIAMETER HIGH SPEED STEEL BLADE.
* ONE BLADE WRENCH.
* ONE GALLON CONCENTRATED COOLANT.
* THREE-YEAR WARRANTY (PARTS ONLY).
* MADE IN THE USA.
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
SQUARE TUBE/DIAGONAL VISE JAWS -------------------- $ 775.00
SPECIAL FORM JAWS (SAMPLES REQUIRED) -------------- $P.O.R.
UNIVERSAL CLAMPING FIXTURE(IF BOUGHT SEPARATELY) -- $1,390.00
VISE PRESSURE REGULATOR (PK/PD) ------------------- $ 285.00
MAG BRUSH ----------------------------------------- $ 95.00
5' Saw Conveyor -------------------------------------- $750.00
10' SAW CONVEYOR ---------------------------------- $1,110.00
20' SAW CONVEYOR ---------------------------------- $1,960.00
Conveyor/Table Back Fence (Sales) -------------------- $155.00
Conveyor Adjustable Guide ---------------------------- $260.00
5' SAW CONVEYOR W/ RHE QUICK-LOC ------------------ $1,290.00
5' SAW CONVEYOR W/ LHE QUICK-LOC ------------------ $1,290.00
10' SAW CONVEYOR W/ RHE QUICK-LOC ----------------- $1,750.00
10' SAW CONVEYOR W/ LHE QUICK-LOC ----------------- $1,750.00
8' DIGITAL QUICK-STOPSYSTEM-CPOLH(INCLUDESCONVEYOR) $7,240.00
8' DIGITAL QUICK-STOPSYSTEM-CPORH(INCLUDESCONVEYOR) $7,240.00
12' DIGITAL QUICK-STOPSYSTEM-CPOLH(INCLUDESCONVEYOR)$8,410.00
12' DIGITAL QUICK-STOPSYSTEM-CPORH(INCLUDESCONVEYOR)$8,410.00
DUAL PALM BUTTONS (CPO SERIES) -------------------- $3,085.00
BLADE GUIDE LASER LIGHT (FACTORY INSTALL) --------- $1,130.00
275 MM SAW BLADE (SPECIFY TOOTH) ------------------ $125.00
315 MM SAW BLADE (SPECIFY TOOTH) ------------------ $ 160.00
350 MM SAW BLADE (SPECIFY TOOTH) ------------------ $ 198.00
350 ECONOMY FABRICATING PACKAGE: (4) 315 MM DIAMETER SAW BLADES, ONE 10' MATERIAL SUPPLY TRACK, 120" MATERIAL STOP TRACK W/ LEFT HAND QUICK-LOC, SQUARE TUBE/ DIAGONIAL VISE JAWS & MAGNETIC BRUSH ----------------------------- $3,085.00
350 ECONOMY FABRICATING PACKAGE: (4) 315MM DIAMETER SAW BLADES, ONE 10' MATERIAL SUPPLY TRACK, 120" MATERIAL STOP TRACK W/RIGHT HAND QUICK LOC, SQUARE TUBE/DIAGONAL VISE JAWS & MAGNETIC BRUSH ---------------------------------- $3,085.00
DELIVERY:
SUBJECT TO STOCK
MAX CAPACITIES:
ROUND TUBING -------------- 90° = 4-1/2 in & 45° = 4 in
ROUND SOLID --------------- 90° = 2 in & 45° = 1 3/4 in
SQUARE TUBING ------------- 90° = 4 1/4 in x 4 1/4 in & 45° = 4 in x 4 in
SQUARE SOLID -------------- 90° = 2 in x 2 in & 45° = 1 3/4 in x 1 3/4 in
RECTANGLE TUBING ---------- 90° = 5 1/2 in x 4 in & 45° = 3 3/4 in X 3 3/4 in
MITER CAPABILITIES ---------- 45° LEFT TO 45° RIGHT
MITER LOCKING DEVICE -------- STOPS @ 45° L, 90° & 45° R
TWO CUTTING SPEEDS
LT ------------------------ 22/44 RPM
HT ------------------------ 44/88 RPM
ELECTRICS ------------------- 230 OR 460V / 3 PHASE (MUST SPECIFY VOLTAGE)
EQUIPPED WITH:
* AIR OPERATED DOUBLE SELF-CENTERING VISE-BURR FREE CUTS.
* PNEUMATIC POWER DOWN FEED WITH ELECTRIC CONTROLS.
* EMERGENCY STOP BUTTON.
* CAPABLE OF SLOTTING.
* DOUBLE REDUCTION, HARDENED AND GROUND WORM & WHEEL GEAR BOX.
* WORM WHEEL OF TOP QUALITY BRONZE.
* CHIP DRAWER.
* SEVEN GALLON COOLANT TANK WITH PUMP.
* ONE 315MM DIAMETER HIGH SPEED STEEL BLADE.
* ONE BLADE WRENCH.
* ONE GALLON CONCENTRATED COOLANT.
* THREE-YEAR WARRANTY (PARTS ONLY).
* MADE IN THE USA.
NOTES:
SPECIFICATIONS SUBJECT TO VERIFICATION
OPTIONAL FEATURES:
SQUARE TUBE/DIAGONAL VISE JAWS -------------------- $ 775.00
SPECIAL FORM JAWS (SAMPLES REQUIRED) -------------- $P.O.R.
UNIVERSAL CLAMPING FIXTURE(IF BOUGHT SEPARATELY) -- $1,390.00
VISE PRESSURE REGULATOR (PK/PD) ------------------- $ 285.00
MAG BRUSH ----------------------------------------- $ 95.00
5' Saw Conveyor -------------------------------------- $750.00
10' SAW CONVEYOR ---------------------------------- $1,110.00
20' SAW CONVEYOR ---------------------------------- $1,960.00
Conveyor/Table Back Fence (Sales) -------------------- $155.00
Conveyor Adjustable Guide ---------------------------- $260.00
5' SAW CONVEYOR W/ RHE QUICK-LOC ------------------ $1,290.00
5' SAW CONVEYOR W/ LHE QUICK-LOC ------------------ $1,290.00
10' SAW CONVEYOR W/ RHE QUICK-LOC ----------------- $1,750.00
10' SAW CONVEYOR W/ LHE QUICK-LOC ----------------- $1,750.00
8' DIGITAL QUICK-STOPSYSTEM-CPOLH(INCLUDESCONVEYOR) $7,240.00
8' DIGITAL QUICK-STOPSYSTEM-CPORH(INCLUDESCONVEYOR) $7,240.00
12' DIGITAL QUICK-STOPSYSTEM-CPOLH(INCLUDESCONVEYOR)$8,410.00
12' DIGITAL QUICK-STOPSYSTEM-CPORH(INCLUDESCONVEYOR)$8,410.00
DUAL PALM BUTTONS (CPO SERIES) -------------------- $3,085.00
BLADE GUIDE LASER LIGHT (FACTORY INSTALL) --------- $1,130.00
275 MM SAW BLADE (SPECIFY TOOTH) ------------------ $125.00
315 MM SAW BLADE (SPECIFY TOOTH) ------------------ $ 160.00
350 MM SAW BLADE (SPECIFY TOOTH) ------------------ $ 198.00
350 ECONOMY FABRICATING PACKAGE: (4) 315 MM DIAMETER SAW BLADES, ONE 10' MATERIAL SUPPLY TRACK, 120" MATERIAL STOP TRACK W/ LEFT HAND QUICK-LOC, SQUARE TUBE/ DIAGONIAL VISE JAWS & MAGNETIC BRUSH ----------------------------- $3,085.00
350 ECONOMY FABRICATING PACKAGE: (4) 315MM DIAMETER SAW BLADES, ONE 10' MATERIAL SUPPLY TRACK, 120" MATERIAL STOP TRACK W/RIGHT HAND QUICK LOC, SQUARE TUBE/DIAGONAL VISE JAWS & MAGNETIC BRUSH ---------------------------------- $3,085.00
DELIVERY:
SUBJECT TO STOCK
