377.5 cu.in./rev KYB #Hydrostar-MRH-375-SW, Radial Piston LSHT Hydraulic Motor, 300 HP, 3570 psi, 60-120 RPM, 175°F max. fluid temperature

KYB Hydrostar MRH-375 SW

• Make: KYB
• Model: Hydrostar MRH-375
• Condition: New
• Heavy Duty Model
• LSHT Motor (Low-Speed, High-Torque)
• SW

  • Standard Shaft
  • SAE 4 Bolt Flange

General Features:

• Speed is Infinitely Variable and Torque Constant Over Entire Speed Range
• Excellent Efficiency Allows Precise Positioning of Driven Equipment
• Rapid Acceleration, Deceleration and Reversing
• Large Main Bearings: Long Life, Allow Heavy Side Load Capacity
  • B10 Life= 5500 Hours (Average Life of Bearings is 22,000 Hours)
• Several Drain Port Locations to Ease Mounting
• Seals Made of Viton
• Commonly Used in Fishing to Forestry, Mining to Marine, Recycling to Shredders, as well as Conveyors and Railroad Equipment.

Specifications

• Displacement Volume: 377.5 in.³/Rev
• Maximum Continuous Pressure: 3570 PSI
• Intermittent Peak Pressure: 4000 PSI
• Maximum Continuous Back Pressure: 350 PSI
• Maximum Continuous Output Torque: 16300 ft-lbs
• Starting Torque at 3570 PSI: 12,700 ft-lbs
• Maximum Continuous Speed @3000 PSI: 120 RPM
• Maximum Continuous Speed @3570 PSI: 60 RPM
• Maximum Continuous Power: 300 HP
• Moment of Inertia (GD²): 9820 lb-in.²
• Maximum Fluid Temperature: 175°F

• Shipping Dimensions: 23.6" Diameter x 25.7" Long
• Weight: 1150 Lbs

• Location: Western Canada
