For Sale by Frank Bacon Machinery Sales
Surplus Record Dealer Since 1956
Location: Warren, MI
Contact Sales Team
Phone Number: 586...> Show Phone Number 586-756-4280
Let the seller know you found their listing on Surplus Record!
Description
30K (150kN) Instron 4483
Instron Model 4483
SPECIFICATIONS:
Tension Testing Opening (Less Tooling): 62"
Compression Testing Opening (Less Tooling): 62"
Distance Between Columns/Screws: 22"
Testing Stroke: 62"
Testing Speed (IPM): .00002 – 20
Crosshead Adjusting Speed (IPM): 20
Approximate Overall Dimensions:
Load Frame (W x D x H): 48" x 32 x 102"
Weight (lbs.): 1,850
Electrical Requirements (V, Hz, PH): 230, 60, 3
EQUIPPED WITH:
- Computer System with Keyboard & Mouse
- 24" LED-backlit LCD Color Monitor
- Microsoft Windows 11 Professional, Workstation.
- MTGenius, Material Testing Software for Data Acquisition (Load, Position, 2 Strain & AUX), Analysis and Computer Controlled Testing with Manual.
- MTGenius, Micro console for sensor excitation and analog/digital signal processing with USB cable.
- Electronic Material Testing Control System in Custom Cabinet/Desk with PC/Manual Controls.
- New AC Servo Motor with Incremental Encoder and Solid State Drive Controller for Precision Control of Testing Rates (Load, Position & Strain).
- 150kN Tension & Compression Load Cell
FOB Warren, MI
Reconditioned/Retrofitted & Certified
1 Year Parts and Labor Warranty
*Images Before Reconditioning
| #Instron 4483
DOWNLOAD SPEC SHEET
Get Your Price from Frank Bacon Machinery Sales!
