Click to zoom in
For Sale by Perfection Global
Surplus Record Dealer Since 1964
Location: Elk Grove Village, IL
Contact Sales Dept.
Phone Number: 847...> Show Phone Number 847-427-3333
Let the seller know you found their listing on Surplus Record!
Description
Specifications
Equipped With
- Cutting Capacity (Mild Steel): 3/8ths x 13' (7/32nds Stainless)
- Max. Cutting Length: 157"
- Distance Between Housings: 167"
- Cutting Angle: 1.5° (Optional Angular Gauge 0°-180°)
- Stroke Speed (STD/FAST): 11/17 SPM
- Throat Depth: 10" (Larger Throat Available)
- Table Height: 35"
- Oil Capacity: 70 Gallons
- Motor: 30 HP
Equipped With
- Cybelec 12G 12" Touch Screen Control
- Standard Servo Motorized Backgauge (39" Travel)
- Programmable Backgauge Retract
- Backgauge Swing-Up Feature for Long Sheets
- Manual Blade Gap Adjustment
- Stroke Adjustment for Short Cutting Efficiency
- Two Edge Upper Blade
- Four Edge Lower Blade
- Transfer Table w/ Roller Balls
- Front Support Arms
- Illuminated Cutting Line
- Foot Pedal
- Many Other Options Available
Get Your Price from Perfection Global!
